1.27*2.54mm DIP Plug Connector Four Row Foot

Shenzhen Antenk Electronics Co., Ltd. introduced a 1.27*2.54mm DIP Plug Connector Four Row Foot.

The development of connector technology presents the following characteristics: high speed and digitalization of signal transmission, integration of all kinds of signal transmission, miniaturization and miniaturization of product volume, low cost of products, tabulation of contact part end connection mode, combination of modules, convenience of plugging and so on. The above technologies represent the development direction of connector technology, but it should be noted that: the above technologies are not necessary for all connectors. Different supporting fields and connectors in different use environments have completely different requirements for the above technologies.

SPECIFICATION
Current Rating:                1.0Amp
Insulation Resistance:         1000MΩ  min
Contact Resistance:            20mΩ  max
Withstand Voltage:             500V AC/DC
Operating Temperature:         -40°C  to  +105°C
Contact Material:              Brass
Contact Plating:               Au or Sn Over Ni
Insulator Material:            PBT+30%GF UL 94V-0
