1.27mm Single Row SMT Female Connector

Shenzhen Antenk Electronics Co., Ltd. promoted a 1.27mm pitch Female Header Single Row SMT Type connector.
We always adhere to the "quality first, integrity and pragmatic" business philosophy, "scientific and technological innovation, excellence" as the principle and dedication to provide customers with quality products and satisfactory service, cherish every opportunity to cooperate with customers.
Shenzhen Antenk Electronics Co., Ltd. specializes in the production and sales of connectors and has been a leading domestic player in the connector industry.

If you need this product, please contact us, thank you!

product information:

1.No.of Contacts: 01To 50.

2.Connector Type: Single Row.

3.Plastic High:5.7mm.(Other sizes can be selected).

4.Insulator Material : PA6T / LCP / PA9T.

5.Packing:Tray / Bag / Tube / Tube+CAP / Tape&Reel / Tape&Reel+CAP.

   SPECIFICATION
Current Rating:                       1Amp
Insulation Resistance:            1000M ohms min
Contact Resistance:               20M ohms max
Dielectric Withstanding:          AC500V
Operating Temperature:          -65°C  to  +125°C
Contact Material:                    Brass
Insulator Material:                   PA6T UL 94V-0 Black
