Stock! Metal Raschig Rings for Rto Random Tower Packing

Stock! Metal Raschig Rings for Rto Random Tower Packing

Get Latest Price

Payment Type:: L/C, T/T, D/P, Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	5000 Cubic Meters/Year
Supply Ability:	5000 Cubic Meters/Year
Payment Type:	L/C, T/T, D/P, Western Union

Product Description

Model NO.: 25mm, 38mm, 50mm, 76mm

Size: 15mm, 25mm, 35mm, 38mm, 50mm, 76mm

Certificate: ISO9001: 2000

Trademark: JINCHENG

Transport Package: by Carton Box, Palletized with Wrapped.

Specification: 16mm, 25mm, 38mm, 50mm, 76mm, 90mm

Origin: China

HS Code: 8419909000

Metal Raschig Ring

Metal Raschig Ring has features such as thin wall, heat resistant, high free volume, high capacity, low resistance, high separation efficiency and so on. It is especially suitable for rectification towers under vacuum to treat thermosensitive, decomposable, polymerizable or cokable systems, so it is widely used in packing towers in petrochemical industry, chemical fertilizer industry and environmental protection, etc.

It is made of materials like carbon steel, stainless steel or Aluminum alloy, etc.

Since 1914 when F. Raschig invented this type of ring for tower packing, random tower packings have been developed extensively. The R-ring is now used in many applications, but particularly in supporting catalyst beds.

Technical data
Sizes (mm)	Bulk density (kg/m3)	Number (per m3)	Surface area (m2/m3)	Free volume (%)
15x15x0.3	379	230000	350	95
25x25x0.4	318	51000	216	96
25x25x0.5	400	51000	220	95
35x35x0.8	430	19000	150	93
38x38x1.58	793	15000	136	94.6
50x50x0.5	203	6500	106	97.4
50x50x0.7	285	6500	108	96.4
50x50x0.8	325	7000	109	95
76x76x0.8	212	1830	69	97.3
80x80x1.2	300	1600	65	96
90x90x1.0	236	1160	62	97
