Rechargeable 3.7V 2500mAh Li-ion Battery Cell For Escooters

Rechargeable 3.7V 2500mAh Li-ion Battery Cell For Escooters

3.7V 2500mAh Li-ion Battery Cell almost the biggest capacity for  battery cell for 3C rechargeable one,

of course, which should fulfillment all marketing quality certification and  other requirements;

For most seconds, the capacity for li-ion battery cell is not the big  problem, as all we know that

even the Samsung and LG Li-ion battery product aslo has the quality issues;

The only way to reduce the potential risk is strength the production standard and testing power.

2.Specification

Ratedcapacity:
Rated capacity: Cap=2000mAh.Under 25±5℃, It means the capacity value of being discharged by 5-hours ratetoendvoltage 3.0V,whichis signedCap,theunitis mAh.
Standardchargemethod:
Under 25±5℃, it can be charged to 4.2V with constant current of 0.5C, and then, charged continuously withconstantvoltage of4.2Vuntilthechargedcurrentis0.01C.
Standarddischargemethod:
Under25±5℃,it canbedischargedtothevoltage of3.0Vwithconstantcurrentof0.5C.
Description and model:
Description:Cylindrical Li-ion rechargeable cell
Model:18650C-2000mAh
Normalvoltage: 3.7V
Chargingvoltage: 4.2±0.05V
Dischargeendingvoltage: 3.0±0.05V
Standard charging current: 0.5C(1000mA)
Standard discharge current : 0.5C(1000mA)
Max charge current: 1.0C
Maxdischargecurrent: 3C
Max recommended charge and discharge cell body temperature: Charge:45℃ Discharge: 60℃
Storage temperature and time : 1year :25℃;  25℃ / 3months :45℃;
Internal resistance: ≤30mΩ(ACImpedance,1000Hz)
Cell dimension:
Height:: 65.0mm
Diameter :18.4mm
Weight: 43g
Cyclelife: 500times
(The rest time after discharge is 5 minutes in this cycle. Perform 3 cycles to check capacity, finishing fully charged. Record capacityof3thcycle. The discharge capacity at the 3th cycle is called the original discharge capacity. The test continues for 500 cycles. Record capacity of 500 cycles )

3-4. Outlook Overview:

4.2 General Package And Remark

_________________________________________________________________________________________

5. Our Story

MKARDA Technology focused on developing the best short distance transportation for human beings, especially for electric scooter area,

which mainly are  electric scooter

5.1 Electric scooter is not a simple work, first you need prepare all metal parts mould, the most important scooter tube parts as below:

5.2 More parts of the electric scooter;

5.3 Assembly Product Line

5.4 OEM&ODM Service are available
