Heated Motorcycle Vest Wireless Battery 12V 15V

The AC801 battery is designed for heavy duty electric heated clothing application.  It has pretty bulk size 35*85*168mm , with two switches and a LED display screen, a 5.5*2.5 coax type socket connector (can be 3.5*1.35mm, 5.5*2.1mm or other type as well).

The AC801 battery LED screen can be made to reflect the battery fuel level status by display number 0~9, 0=empty, 9=full.

The AC801 battery can be made to have different output mode: Constant DC type, Pulse DC type (adjustable pulse settings), or two both.  Asarke Heated Clothing Battery is using Pulse-Width Modulation(PWM) or Pulse-Duration Modulation (PDM) technology which able to control/adjust the output power rate thus achieve desirable heat level in heater. Pulsed DC (PDC) or pulsating direct current is a periodic current which changes in value but never changes direction, pulsating direct current is used on PWM controllers.

The AC801 battery is perfect for higher power drain heated clothing like those for motorcycle riders. It is also idea back up battery for light 7v heated clothing when user stay in one place not in moving and need keep warming up.

Typical Capacity Option:
7.4v 8800mAh/10400mAh/12800mAh/13600mAh
11.1v 7000mAh/8000mAh/9000mAh/10000mAh
14.8v 4400mAh/5200mAh/6400mAh/6800mAh

Battery Case ID: AC801
Cell inside: Lipo cells or 6pcs/8pcs li ion 18650 battery

Dimension: 35*85*168mm
Input/Ouput Terminal: 5.5*2.5,5.5*2.1,3.5*1.35mm
or designated connector in extension cable.
Weight: 350~470g
Function Code: CS, CC, PC, DM

Application: coat with heater built in, battery heated pants, heated hoodie canada, other types electric heated glove or electric heated gears.
