740nm Far Red IR LED SMD 60-Degree 200mA

740nm Far Red IR LED SMD 60-Degree 200mA

Get Latest Price

Min. Order:: 4000 Piece/Pieces

Min. Order:: 4000 Piece/Pieces

Transportation:: Ocean, Land, Air, Express, Others

Port:: Shenzhen

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	1000000000 pcs/week
Supply Ability:	7000000000 pcs/week
Payment Type:	T/T,Paypal
Incoterm:	EXW,FOB,FCA
Certificate:	GB/T19001-2008/ISO9001:2008
HS Code:	8541401000
Transportation:	Ocean,Land,Air,Express,Others
Port:	Shenzhen

Product Description

What's the different of both 740nm LED?

There are 2 kinds of 740nm LED in 2835 SMD LED 60 degree lens: 2835FIRC74L14I60A60 and 2835FIRC74L20I200A60; They looks similar in the part number. Acutally when you put both of this product in the table, you cannot even tell the different. Because the only different in these 740nm LED is the chip inside. We cannot see the chip very clear becuase the dome lens, that's why we tell there will be looks the same from ourside. For 2835FIRC74L14I60A60, the max operation is 60mA. The 2835FIRC74L20I200A60, the max opeartion is 200mA. Which means the later one will emits higher radiation because it can handle higher current.

2835FIRC74L20I200A60 740nm Far Red IR LED SMD 60-Degree 200mA

Electrical Parameters:

Parameter	Symbol	Rating	Unit
Reverse Voltage	VR	5	V
Junction Temperature	Tj	100	℃
Operating Temperature	Topr	-40 - +80	℃
Storage Temperature	Tstg	-40 - +100	℃
Soldering Temperature	Tsol	260	℃
Electro-Stati-Discharge(HBM)	ESD	1000	V
Service lige under normal conditions	Time	60000	H
Warranty	Time	2	Years
Antistatic bag	Piece	2000	Bag

*Pulse forward current confition: Duty 1% and Pulse width=10us.

*Soldering confition: Soldering confition must be completed with 3 secongds at 260℃

Parameter	Symbol	Rating	Unit
Forward Current	IF	200	mA
Forward Voltage	V	1.7-2.0	v
Luminous Intensity	IV	0.6-1.2	lm
Wavelength	λP	740	nm
Packing	Piece	2000	Reel
Viewing angle	2θ1/2	60	Deg
