PC Amber 2016 SMD LED 1800K White LED

What is an amber LED color?

In Spectrum, the amber color are in between of gold yellow and orange. Compare with gold yellow LED, amber LED will looks orange-ish. We package this amber LED with 2016 SMD LED case and produce it with the same progress as white SMD LED. So we can name this as super warm white LED with 1800K color temperature. Because of there have a yellow phosphor converted on the top of SMD LED, this also name as PC amber LED.

We can also produce the amber LED with 595nm LED chip inside of package and cover with clear lens on the top. But compare with that, this blue chip inside and phosphor converted SMD LED will got much more competitive price and higher brightness.

Electrical Parameters:

*Luminous intensity is measured by ZWL600.

*λD is derived from the CIE chromaticity diagram and represents the single wavelength which defines the color of the device.

Size of 2016 LED SMT:

*UV LED, Red SMD LED, Yellow LED, Blue SMD LED are all available in this 2016 SMD LED size.*

Product Details:

99.99% purity gold wire;

Silver plated LED frame;

Famous branded chips;

High quality epoxy;

Production progress:
