Super Bright 3528 RGB LED Black Casing

Get Latest Price

Min. Order:: 10000 Piece/Pieces

Min. Order:: 10000 Piece/Pieces

Transportation:: Ocean, Land, Air

Port:: SHENZHEN

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	1000000000 pcs/week
Supply Ability:	7000000000 pcs/week
Payment Type:	T/T,Paypal
Incoterm:	FOB,EXW,FCA
Certificate:	GB/T19001-2008/ISO9001:2008
HS Code:	8541401000
Transportation:	Ocean,Land,Air
Port:	SHENZHEN

Product Description

- 3528 RGB LED -

3528RGB-10B

Kinds of SMD LED case are available in 3528 RGB LED, there have two pins 3528 SMD LED case for RGB LED flicker. PLCC4 3528 SMD LED case for RGB LED. Or even 6 pins for this 3528 RGB LED. Besides the pins, the color of surface are also available in white or black color. And at the same time, the lens that cover the chips can also be clear or diffused. With clear lens, you will get longer emitting distance and you will got more diffused bright light. You will be able to choose the one you need for your project. Because of the high brightness, small size and the uniform color, this 3528 RGB LED are widely use in LED display project and some other LED lighting project.

3528 RGB LED black case

- Size: 3.5*2.8*1.9mm

- Chip Number: 3 chips

- Color: RGB LED

- Type: Surface mount device

- Chip brand: Epistar

- Common Anode

- Different color are available

- Different wavelength are available

- Warranty: 5 Years

- RoHS, REACH, EN62471

- Uniform light output

- Long life-solid state reliability

- Low Power consumption

-Anti UV epoxy resin package

-High temperature resistance

-Dimension Parameters-

3528 multi-color LED

These SMD LED case are also available for IR LED, UV LED, Blue SMD LED, Red SMD LED, Amber LED ect.

- Emitting Color -

- Electrical Parameters -

Parameter	Symbol	Rating			Unit
		Red	Green	Blue

Power Dissipation	Pd	75	105	105	mw
Pulse Forward Current	IFP	200	200	200	mA
Forward Current	IF	30	30	30	mA
Reverse Voltage	VR	5	5	5	V
Junction Temperature	Tj	110			°C
Operating Temperature	Topr	-40 ~ +80			°C
Storage Temperature Range	Tstg	-40 ~ +100			°C
Soldering Temperature	Tsol	260			°C
Electro-Static-Discharge(HBM)	ESD	2000	2000	2000	V
Service life under normal conditions	Time	80000			H
Warranty	Time	5			Years
Antistatic	Piece	2000			Back

Optical and Electrical Characteristics( Tc=25℃)

Parameter

Symbol

Min

Typ

Max

Unit

Test Condition

Forward Voltage	Red	VF	1.8	2.0	2.4	V	IF=20mA
	Green		2.8	3.0	3.4
	Blue		2.8	3.0	3.4
Luminous Intensity	Red	IV	500		800	mcd	IF=20mA
	Green		1400		1800		IF=20mA
	Blue		400		700		IF=20mA
Peak Wavelength	Red	λP		633		nm	IF=20mA
	Green			527
	Blue			462
Dominant Wavelength	Red	λD	618	620	626	nm	IF=20mA
	Green		517	520	525
	Blue		463	465	468
Half Width		Dl		18		nm	IF=20mA
Viewing Half Angle		2q1/2		±60		deg	IF=20mA
Reverse Current		IR			5	uA	VR=5V
