XFP to SFP 10G 3R Repeater

XFP to SFP 10G 3R Repeater

When the device transceiver channel is working, the output parallel data in the FPGA architecture is transmitted through the transmitter PCS and PMA, and finally converted into serial data and sent out.

The XFP to SFP 10G 3R Repeater are 10G fiber to fiber 3R repeater and transponders. Based on a number of 10 Gigabit Fiber standards, these transponders support XFP to XFP, SFP+ to XFP, and SFP+ to SFP+ fiber connections. XFP to SFP 10G 3R Repeater transponders are protocol transparent, providing 3R (Re-amplification, Re-shaping and Re-clocking) regeneration between these different optical module types. One of the major applications is in connecting proprietary transceiver equipment to CWDM or DWDM when these 'colored' optical modules are not available for the proprietary equipment. With full duplex wire speed forwarding capability between the 2 fiber media, the XFP to SFP 10G 3R Repeater bring you the best and simplest solution for your 10G conversion between fiber and fiber.

10G 3R Repeater Features

• Multiple protocol supported 10G Ethernet, 10G FC, STM-64, OC-192

• Protocol transparent 3R fiber media transponder / repeater (Re-amplification, Re-shaping and Re-clocking)

• Hot Pluggable SFP+ or XFP transceiver

• 10G ports offering multiservice; 10G transponder and regenerator function

• Provides superior optics capabilities resulting in extended transport distances for regional application.

• Extend 10G Ethernet transmission over fiber

• Useful as a 'Transponder' in CWDM or DWDM systems for 10G Ethernet/Fiber Channel/STM-64

• Application for network backbones, such as R&D laboratory, Data center etc.

3R Repeater 10G Application

10Gigabit Internal Mode Converter Ordering  information
