L2 Managed Gigabit Switch with 8 Ethernet Ports

 N-net L2 Managed Gigabit Switch with 8 Ethernet Ports

The NT-MG2800 is an 8-Port 10/100/1000Mbps Web Smart Gigabit Ethernet Switch. For efficient management, with its built-in Web-based management, this Ethernet switch offers an easy-to-use and configuration facility. Via the WEB interface, the managed switch can be programmed for basic switch management functions such as per port speed duplex settings, Port Trunking, VLAN, Port Mirroring, Rapid Spanning Tree, 802.1X network security authentication and Misc Configuration. Additionally, the firmware includes advanced features such as IGMP snooping, QoS (Quality of Service), broadcast storm and bandwidth control, to enhance bandwidth utilization

10/100/1000M Network Switch Features

1. Comply with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T, IEEE802.3z 1000Base-SX/LX Ethernet standard
2. Auto-MDI/MDI-X detection on each RJ-45 port
3. Prevents packet loss with back pressure (half-duplex) and 802.3x PAUSE frame flow control (Full-duplex)
4. 8K MAC address table, automatic source address learning and ageing
5. 20Gbps switch fabric, non-blocking switch architecture
6. 9.6K Jumbo Frame support at all speed (10/100/1000 Mbps)

Layer 2 Switching

Support port-based and 802.1q VLAN function, up to 4096 VLAN groups

802.1w Rapid-Spanning Tree protocol support

Link Aggregation support static mode and LACP (802.3ad) - up to 5 Trunk groups, each trunk for up to maximum 10 ports

IGMP Snooping – multicast filtering

L2 Managed Switch Application

Managed Gigabit Ethernet Switch NT-MG2800 series
