Unmanaged 4 Ports Fast Ethernet POE Switch
- Payment Type:
- L/C, T/T, Paypal, Money Gram, Western Union
- Incoterm:
- FOB, CIF, FCA
- Min. Order:
- 1 Piece/Pieces
- Min. Order:
- 1 Piece/Pieces
- Delivery Time:
- 4 Days
- Transportation:
- Ocean, Land, Air, EXPRESS
- Port:
- China
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 5000pcs/day |
| Supply Ability: | 5000PCS around 10-20 days |
| Payment Type: | L/C,T/T,Paypal,Money Gram,Western Union |
| Incoterm: | FOB,CIF,FCA |
| Certificate: | CE, FCC,ISO9001 |
| HS Code: | 8536700000 |
| Transportation: | Ocean,Land,Air,EXPRESS |
| Port: | China |
N-net Unmanaged 4 Ports Fast Ethernet POE Switch
NT-1600-AF4 is a 10/100M POE switch that create a small network for SOHO and small & medium-sized business. From the appearance, it's easier to know the power over ethernet ports with yellow surrouding. The unplink port of this POE switch is a fiber port that transmission can be up to 120km. Power of POE switch supports up to 30w and standard power is 15.4W. With high technology and years experience, N-net team sincerely provides kinds of sollutions for you.
4 Ports Ethernet POE Switch Features
1. 10/100Mbps auto-sensed, facilitating network upgrade
2. Built-in efficient switching core to implement flow control and reduce broadcast packets
3. Providing several respective 10M/100Mbps adaptive twisted pair switching ports which implement the backup of electrical ports and the access of multiple users
4. Supporting full-duplex and half-duplex and its auto-sensed
5. Supporting auto-sense of MDI/MDI-X, facilitating system commissioning and installation
6. Supporting the transmission of extra-long packets up to 1552 bytes
7. Low power consumption, reliable and stable performance;
8. Options in single mode in dual fiber, multi-mode in dual fiber, and single mode in single fiber
Specifications
|
Item |
Unmanaged Fast Ethernet POE Switch |
|
Parameter |
Specifications |
|
Access mode |
10/100Mbps |
|
Standard |
IEEE802.3 10Base-T Ethernet, IEEE802.3u,100Base-TX/FX Fast Ethernet, IEEE802.3x Flow control |
|
Wavelength |
850nm/1310nm/1550nm |
|
Transmission distance |
Multi-mode Dual-fiber: 2 km; Single mode Dual-fiber: 20/40/60/80/100/120 km; Single mode Single fiber: 20/40/60/80/100/120 km Category-5 twisted pairs: 100m |
|
Port |
RJ45 port: Connecting with STP/UTP category-5 twisted pairs Optical port: Multi-mode: SC or ST (50, 62.5/125μm) Single mode: SC or FC (9/125μm) Single mode Single fiber: SC/FC (9/125μm) |
|
Flow control |
Full duplex: flow control; half duplex: back pressure |
|
Error rate |
<10-9 |
|
MTBF |
100,000 hours |
|
LED indicator |
POWER (power supply); FX LINK/ACT (fiber link/action) FDX (FX full duplex), FX100 (fiber rate 100M) |
|
Power supply |
DC52V 1.25A (external) |
|
Power consumption |
3.5W |
|
Operating temperature |
-10~55ºC |
|
Operating humidity |
5%~90% |
|
Maintaining temperature |
-40~70ºC |
|
Maintaining humidity |
5% ~ 90% non-condensing |
|
Dimensions |
110mm(W)×82mm(D)×47mm(H) (external power supply) |
Small Fast Ethernet POE Switch Application
POE Switch 10/100M Series
|
NT-1600 |
10/100Base-T to 100Base-F, 6TP ports, multi-mode, 2km, SC, standalone, external power adaptor |
|
NT-1600S-25 |
10/100Base-T to 100Base-F, 6TP ports,single mode, 25km, SC, standalone, external power adaptor |
|
NT-1600S-40 |
10/100Base-T to 100Base-F, 6TP ports,single mode, 40km, SC, standalone, external power adaptor |
|
NT-1600S-60 |
10/100Base-T to 100Base-F, 6TP ports,single mode, 60km, SC, standalone, external power adaptor |
|
NT-1600S-80 |
10/100Base-T to 100Base-F, 6TP ports,single mode, 80km, SC, standalone,external power adaptorr |
|
NT-1600S-100 |
10/100Base-T to 100Base-F, 6TP ports, single mode, 100km, SC, standalone, external power adaptor |
|
NT-S1600-25 |
10/100Base-T to 100Base-F, 6TP ports, WDM(single fiber bi-direction), 25km, SC, standalone, external power adaptor |
|
NT-S1600-40 |
10/100Base-T to 100Base-F, 6TP ports, WDM(single fiber bi-direction), 40km, SC, standalone, external power adaptor |
|
NT-S1600-60 |
10/100Base-T to 100Base-F, 6TP ports, WDM(single fiber bi-direction), 60km, SC, standalone, external power adaptor |
|
NT-S1600-80 |
10/100Base-T to 100Base-F, 6TP ports, WDM(single fiber bi-direction), 80km, SC, standalone, external power adaptor |
|
NT-S1600-100 |
10/100Base-T to 100Base-F, 6TP ports, WDM(single fiber bi-direction), 100km, SC, standalone, external power adaptor |
