150W DALI 12V 24V dimmable led power supply

Get Latest Price

Payment Type:: T/T, Paypal, Western Union

Incoterm:: EXW

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Delivery Time:: 10 Days

Transportation:: Ocean, Air

Port:: SHENZHEN

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	10000pcs/day
Supply Ability:	10000pcs/day
Payment Type:	T/T,Paypal,Western Union
Incoterm:	EXW
Certificate:	ISO9001
HS Code:	85044014
Transportation:	Ocean,Air
Port:	SHENZHEN

Product Description

150W DALI 12V 24V dimmable led power supply

150W DALI 12V 24V dimmable led power supply,support DALI1 &DALI2 protocol,constant current and constant voltage triac dimmable 12V 24V led driver,use for led strip light,led panel light,RUBYCON capacitor with 5years warranty

Product Features and Advantage

1.Electable and customzied constant current/constant voltage output.

2.Rubycon capacitor with 5years warranty

3.Wattage from 9-400W

4.High Efficency to 90%,High power factor can be 0.99

5.Full dimmable solution:Triac/0-10v/DALI/PWM/PUSH/ZIGBEE

6.5 years quality warranty

150W DALI 12V 24V dimmable led power supply:

constant voltage :

Model No.	HDL-CV-150
Input Voltage Range	100-240V/AC
AC Frequency	48-62Hz
Output Mode	Constant voltage
Output Current	12500ma 6250ma 4000ma
No Load Voltage	12V 24V 36V
Output Power	150W Max.
Power Factor	>0.95
Efficiency	>80%
Dimensions	1745635(mm)

constant current :

Model No.	HDL-CV-150
Input Voltage Range	100-240V
AC Frequency	48-62Hz
Output Mode	Constant current
Output Current	900&1200&1500&1800 ma
No Load Voltage	80&60&48&40 v
Output Power	60w
Power Factor	0.95
Efficiency	82%-86%
Dimensions	1745635(mm)

Environmental Specifications :

Operating Temperature:-25~+55°C

Storage Temperature : -40~+70°C

Thermal Dissipation : Nature

Relative Humidity:5~95%

Isolation Voltage:In/Out 3000VAC

Vibration:5-55Hz/2g,30 Mimutes

Life Time:50000Hours,at TC max

Intrudction

1. a plant of 1000 square meters,over 50 employees;

2. 5~9 days delivery time, 5 years warranty;

3. TUV ETL, CE, RoHS SAA certifications;

4. Strong R&D teams,with at least 2 new models released monthly;

5. Large stock of materials;

6. Strict quality check process, tested for at least 24hrs before delivery;

7. Neutral Package, or customer color box package upon requirements.

8. Pay attention to innovation, high quality and reasonable price

About sample and mass production:

Dear buyer arrange the sample cost and freight(if you have express account,provide it),sample time:3 working days,after confirmed the sample, dear buyer arrange the deposit and we will finish it 10- 15 days after got the deposit,balance before deliver,your own courier or we arrange is possible.

About packing:

white box ,inner box,and carton etc or customized

Quality guarantee:

All the driver have automatic protection of overload, short circuit, temperature,etc.

The warranty period is 5years.

During the time ,if the product have any question ,we can change the same to you.

We can design the product according to your requirement.
