Manufacture Traffic Barrier Bollard with Control Unit
Traffic Bollard Description:
Hydraulic Bollards(Traffic Bollard) can be installed in sets with 1,2,3 and 4 units. When 2,3 and 4 units of sets are used, all units are controlled with one cabinet and they open-close at the same time.When the up button in the control keyboard is pressed, the bollards move up and prevent car access.
Traffic Bollard Technician data:
| 1 | control system | Hydraulic control system |
| 2 | Pressure-bearing | ±100 ton vehichel |
| 3 | Anti-collision grade | K4 |
| 4 | Protection grade | IP68(waterproof.dampproof.dampproof). |
| 5 | Power supply | 380V |
| 6 | Power(w) | 2.7KW |
| 7 | rise time | 5~10S(adjustable) |
| 8 | Drop time | 5~10S(adjustable) |
| 9 | Work temperature | -25℃~75℃ |
| 10 | Storage condition | -10℃~75℃. |
| 11 | Color | stainless steel(default),multiple colors reflection film/led indication (optional) |
| 12 | Material | 304 stainless steel |
| 13 | Bollard size(mm) | L400×W400×H910, rise/drop height: 600mm,panel size:600x600mm. |
| 14 | Bollard diameter(mm) | 168\219(default)\275mm;thickness: 6mm(8-10-12mm optional). |
| 15 | Control ways ( optional) | remote control, manual operation, rfid card, bluetooth card, |
| 16 | Weight | 110KG |
Traffic Bollard Function:
1,No need lay underground hydraulic pipeline. Easy installation. Low construction cost
2,Because of Have no hydraulic pipeline. It only need inspect independent bollard during maintenance.
it is easy to take out the control box from earth .Easy repair and maintenance
System takes of micro motor and a integration ports connect gear pump and oil box . Then use a all in
one hydraulic cylinder to built a complete micro hydraulic .use structure parts to install this system into
roadblock inner.In this way complete electronic energy >mechanical energy>hydraulic energy conversation process .totally reach micro .electronic.;liquidize integration
Related Product:Automatic Bollards,Automatic Pneumatic Steel Bollards,Reflective Automatic Bollard,Stainless Steel Automatic Bollard,Rising Bollard,Security Bollard,Retractable Bollards,Automatic Bollard,Hydraulic System Rising Bollards,Hydarulic Bollards,Hydarulic Bollard,Hydraulic Rising Traffic Bollards,Electric Rising Hydraulic Bollards,Automatic Road Rising Bollard,Rising Bollards,Security Bollards,Retractable Security Bollard,Automatic Security Bollard,Durable Traffic Bollard,Removable Traffic Bollard,Traffic Bollards,Elastic Plastic Traffic Bollards
Traffic Bollard Features :
(1) Emergency release ;
(2) There is no limited on distance between Independent bollard and control system
(3)Can make sure more than one bollard synchronous raise and fall
(4)Can takes of short/remote control and short swing card or long range radio swing card control .
(5)Can connect with PC reach sequencing control.Suitable for high frequency high safety requirement
place
