304 Stainless Steel Automatic Hydraulic Bollard with LED Light
Traffic Bollard Description:
The bollard (Traffic Bollard) post is designed to vertically move in a flanged cylindrical housing (this is also made of Fe steel and cataphoresis treated), which is fixed into a foundation sleeve, ie. a cylindrical container set into the ground in a concrete foundation. The up and down motions of the traffic control post are allowed by means of an inner electro-hydraulic mechanism consisting of a motor pump unit that vertically operates a piston inside an actuator supported by three guide rods. These have the purpose to steadily drive the post to fully up and down limit positions of the piston stroke. Two electro-mechanical limit switches stop the motor unit when the post has reached either ends of the permitted stroke.
Related Product: Automatic Pneumatic Steel Bollards,Reflective Automatic Bollard,Stainless Steel Automatic Bollard,Rising Bollard,Security Bollard,Retractable Bollards,Automatic Bollard,Hydraulic System Rising Bollards,Hydarulic Bollards,Hydarulic Bollard,Hydraulic Rising Traffic Bollards,Electric Rising Hydraulic Bollards,Automatic Road Rising Bollard,Rising Bollards,Security Bollards,Retractable Security Bollard,Automatic Security Bollard,Durable Traffic Bollard
Removable Traffic Bollard,Traffic Bollards,Elastic Plastic Traffic Bollards
Traffic Bollard Technician data:
| 1 | control system | Hydraulic control system |
| 2 | Pressure-bearing | ±100 ton vehichel |
| 3 | Anti-collision grade | K4 |
| 4 | Protection grade | IP68(waterproof.dampproof.dampproof). |
| 5 | Power supply | 380V |
| 6 | Power(w) | 2.7KW |
| 7 | rise time | 5~10S(adjustable) |
| 8 | Drop time | 5~10S(adjustable) |
| 9 | Work temperature | -25℃~75℃ |
| 10 | Storage condition | -10℃~75℃. |
| 11 | Color | stainless steel(default),multiple colors reflection film/led indication (optional) |
| 12 | Material | 304 stainless steel |
| 13 | Bollard size(mm) | L400×W400×H910, rise/drop height: 600mm,panel size:600x600mm. |
| 14 | Bollard diameter(mm) | 168\219(default)\275mm;thickness: 6mm(8-10-12mm optional). |
| 15 | Control ways ( optional) | remote control, manual operation, rfid card, bluetooth card, |
| 16 | Weight | 110KG |
Traffic Bollard Function:
1,No need lay underground hydraulic pipeline. Easy installation. Low construction cost
2,Because of Have no hydraulic pipeline. It only need inspect independent bollard during maintenance.
it is easy to take out the control box from earth .Easy repair and maintenance
System takes of micro motor and a integration ports connect gear pump and oil box . Then use a all in
one hydraulic cylinder to built a complete micro hydraulic .use structure parts to install this system into
roadblock inner.In this way complete electronic energy >mechanical energy>hydraulic energy conversation process .totally reach micro .electronic.;liquidize integration
Traffic Bollard Features :
(1) Emergency release ;
(2) There is no limited on distance between Independent bollard and control system
(3)Can make sure more than one bollard synchronous raise and fall
(4)Can takes of short/remote control and short swing card or long range radio swing card control .
(5)Can connect with PC reach sequencing control.Suitable for high frequency high safety requirement
place
