Product Description

Fahold's LED drivers solve the compatible problem between fluorescent lamps and LED lamps very successfully. They are widely used with various kinds of capacity dimming system to control the LED ceiling light, LED downlight, LED panel lights, LED wallwashers, LED strip lights and so on. Our 0-10V/1-10V dimmers support both linear and logarithmic dimming curve, dimming the lights very smoothly and are compatible with various famous lighting control systems, such as Lutron, Dynalite, Schneider, Clipsal, Osram, Philips, ABB and so on.

Product Feature

Single channel output, output current level selectable by DIP S.W.
Support 1-10V analog dimming signal, Passive or active signal.
Wide range of input voltage 100VAC ~ 120VAC
High efficiency up to 84%
Built-in active PFC function
100% output when no dimming signal input, can be used as normal power supply
Dimming effect smooth, non-flicker
Protections: Short circuit.
Suitable for indoor LED lighting application

Technical Parameter:

Product Name		Dimming Power Driver 60W
Item		HN60W-02
Output	Current	300mA	1500mA
	DC Voltage	25-40V	25-40V
	Rated power	--	60W
	Current Accuracy	±3%
	R & N (Max)	75mAp-p
	Channels	1
Input	Voltage Range	100VAC – 120VAC
	Frequency Range	50 – 60Hz
	Efficiency(Typ)	87%
	Power Factor(Typ)	≥ 0.98@180VAC
	AC Current(Typ)	0.11A@230VAC
	Leakage Current	<5mA/240VAC
	Inrush current(Typ)	<1A at 230VAC
Protection	Short Circuit	Output close, recovers automatically after fault removed
Function	Dimming	NO
Others	Dimension	188(L) 76(W)33(H)mm
	Working temp.	-20℃ ~ 50℃
