IP67 Rainproof LED Driver 24V 36V 48V

FD-160H-024, designed specifically for LED Street lights, led canopy lights applications, to operate general Outdoor Lighting Solution. IP67 waterproof design,with 0-10V,PWM,RX dimming,pass the UL Certiication with 5years warranty.input 100-277V,the biggest output current can do the 5A,hot sale in this market.
Standard features of this LED lighting driver include short circuit, over load, over voltage & over temperature protections and the unit is designed to meet TUV, EN61347-1, EN61347-2-13 and emmisions to EN 55105, EN61547.

Features & Benefits

· High PFC
-Aluminum case led driver
· Single channel output, output current level selectable.
· Wide range of input voltage 100VAC ~ 277VAC
· High efficiency up to 93%
· Built-in active PFC function
· 100% output dimming signal input, can be used as normal power supply
· Protections: Short circuit,over load, over voltage & over temperature protections
· Suitable for indoor LED lighting application

OEM & ODM are welcome.
Sample fee: negotiable, sample can be supplied in 5 days.
High quality, complete kinds, good stability, strong practicability.
Good after-sales service & point to point technical supports.
Energy saving, long using life.
Compatible with systems of Crestron, Philips, Osram, Lutron, Dynalite, Clipsal, LDS, ABB, Schneider, Leviton, JUNG, Berker, Be Lichtregler, etc.
Widely used in hotel, office, hospital, market, home, outdoor, indoor, hall, stage, etc.

Product Specs

Output voltage:24-38V
Max. Output wattage: 150W
Max. Output Current: 5000mA
Dimensions:216x66x38mm
Efficiency:93%
Electronic Led Dimmer
Encironment/IP Rating: outdoor/IP67
Flicker free
Max. Input voltage:277V
Certificate:UL,FCC,CE
