(CV) Constant Voltage 24V LED Drivers Power Supplies

Details

FD-80H-024B, Aluminum case constant voltage LED Driver, Designed for outdoor lights applications. Flicker free 60W 2700mA, with UL,FCC,RCM,CB,CE compliant, wide voltage output of IP67 waterproof design. The units are suitable for street lights & high wattage strip light. Other standard features of the range include 100-277V , protections against short circuit, over load and thermal to 110 °C, across the whole surface of the unit.

Standard features of this LED lighting driver include short circuit, over load, over voltage & over temperature protections and the unit is designed to meet UL8750,  EN61347-1, EN61347-2-13 and emmisions to EN 55105, EN61547.

Features & Benefits

· High PFC

· IP67 Waterproof

· Single channel output, output current level selectable.

· Wide range of input voltage 100VAC ~ 277VAC

· Built-in active PFC function

· 100% output  dimming signal input, can be used as normal power supply

· Protections: Short circuit,over load, over voltage & over temperature protections

· Suitable for Outdoor LED lighting application

Product Specs:

Output voltage:24V

Max. Output wattage: 60W

Max. Output Current: 2700mA

Dimensions:152X66X38mm

Efficiency:90%

Encironment/IP Rating: outdoor/IP67

Flicker free

Max. Input voltage:277V

Certificate:UL, FCC ,RCM,CE

FD-80H-24 Constant Voltage driver, Flicker free LED Driver, Desigen for high lumen Outdoor lightings, Energy saving driver. Its housing was made out of bright Aluminum,  independent design for the output connection structure, suitable for North American & Europe market.
