Fan Cowl Panel Latch Injection Mould
- Payment Type:
- T/T
- Incoterm:
- FOB
- Min. Order:
- 1 Set/Sets
- Min. Order:
- 1 Set/Sets
- Delivery Time:
- 40 Days
- Transportation:
- Ocean
- Port:
- Shenzhen
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 500K shots |
| Supply Ability: | 30 sets per month |
| Payment Type: | T/T |
| Incoterm: | FOB |
| Certificate: | ISO 9001:2008 |
| HS Code: | 8480719090 |
| Transportation: | Ocean |
| Port: | Shenzhen |
Each mold is evaluated by a specific technical study, that search for the correct balance between quality, molded parts, mold productivity and automation simplicity.
Our technical department is able to design and provide high quality tools,make our customers to be more efficient in production.Customised solutions in order to satisfy market needs and support production results, giving an important consulting service for mould manufacturing.
Please contact 3K Mold today, we are looking forward to working with you together.
| Project Information | ||
| Product Description | Part Name | Fan Cowl Panel Latch Injection Mould |
| Part Material | ABS | |
| Part Size(mm) | 357.7x343x61 | |
| Mould Description | Cavity Insert Material | P20 |
| Core Insert Material | P20 | |
| Slider Insert Material | ||
| Mould Cavities | 1 | |
| Mold parts Standard | Hasco | |
| Mold Size | 700X600X491mm | |
| Mold weight | 1496 kg | |
| Lead time | 5 weeks | |
| Mould Life Time (Shots) | 500K | |
| Mould Type | Export to Germany | |
| Runner Description | Incoe | |
| Injection Gate Type | 1 Incoe hot tip | |
| Ejection System | Ejector block | |
| Cycle time | 35S | |
| Slide Qty. | 0 | |
| Lifter Qty. | 0 | |
| Injection moulding machine | 350T |
3K Mold is ISO-9001: 2008 certified. We use formal quality systems to manage the overall quality process and use precision measurement facilities by our well-trained team. All tooling and parts produced at our facility are constantly monitored by our Quality Assurance Department to meet your specifications.
Quality control Center
3K team committed to meet customer quality and delivery request. The main quality control process as following:
Incoming quality control (IQC)
In process quality control (IPQC)
Quality assurance (QA)
Quality management flow:
1. Mold base inspection
2. Steel inspection
3. Mold component inspection
4. Electrodes inspection
5. Mold checking before assembly
6. (FAI, CPK) First Article dimension report
7. Mold checking before delivery
