BODY CALIPER Plastic Injection Moulding
- Payment Type:
- T/T
- Incoterm:
- FOB
- Min. Order:
- 1 Set/Sets
- Min. Order:
- 1 Set/Sets
- Delivery Time:
- 45 Days
- Transportation:
- Ocean
- Port:
- Shenzhen
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 1000K shots |
| Supply Ability: | 30 sets per month |
| Payment Type: | T/T |
| Incoterm: | FOB |
| Certificate: | ISO 9001:2008 |
| HS Code: | 8480719090 |
| Transportation: | Ocean |
| Port: | Shenzhen |
Capacity and Technology:
3K Mold Co.,Limited, a leading edge specialist in plastic injection mould toolmaking and product design, we always combine leading top technology alongside superb manual skills to produce the finest possible tooling.
We have the machine capacity to tackle larger projects, to a weight of 10 tons. Our high specification CNC machining and CNC spark erosion centres machine to a size of 1500 x 900 x 600, and spark to a manufacturer`s stated accuracy of half a micron,we also a part of our commitment to ISO9001 certification.
We were champions in the category of `Supplier Partnership – Toolmaker`, which focuses on a Toolmaking company`s ability to work effectively in partnership with their customers, to achieve the customer`s goals.
| Project Information | ||
| Product Description | Part Name | BODY CALIPER Plastic Injection Moulding |
| Part Material | ABS+PC | |
| Part Size(mm) | 210*145*123 | |
| Mould Description | Cavity Insert Material | 1.2343 HRC50-52 |
| Core Insert Material | 1.2343 HRC50-52 | |
| Slider Insert Material | 1.2343 HRC50-52 | |
| Mould Cavities | 2 | |
| Mold parts Standard | Hasco | |
| Mould Life Time (Shots) | 1,000,000 | |
| Mould Type | Export to Germany | |
| Runner Description | Hot runner | |
| Injection Gate Type | 4 points pin gate | |
| Ejection System | Ejector Pin | |
| Slide Qty. | 2 | |
| Lifter Qty. | 6 | |
| Injection moulding machine | 280T |
3K Mold is ISO-9001: 2008 certified. We use formal quality systems to manage the overall quality process and use precision measurement facilities by our well-trained team. All tooling and parts produced at our facility are constantly monitored by our Quality Assurance Department to meet your specifications.
Quality control Center:
3K team committed to meet customer quality and delivery request. The main quality control process as following:
Incoming quality control (IQC)
In process quality control (IPQC)
Quality assurance (QA)
Quality management flow:
1. Mold base inspection
2. Steel inspection
3. Mold component inspection
4. Electrodes inspection
5. Mold checking before assembly
6. (FAI, CPK) First Article dimension report
7. Mold checking before delivery
