LONG  LIFE LFP12280L  BATTERY

The   LFP12280L  BATTERY is desgined for general purpose and long life, focus on improving trickle life that base on FP series. Main features as follow:


  When it is used in safe surroundings, the battery is maintenance free, no need adding water and it can be recharged repeatedly.

ü   With isolated seal, it can be put in horizontal way, vertical way and side way, its safety and functions totally will not be affected.

ü   With special formula to manufacture lead calcium alloy as well as automatic progresses, gassing will be less.

ü   Long life, low self-discharge rate and high reliability.

ü   It has safety, low resistance so recharge is easy and energy output is more remarkable.

ü   Container material could be frame retardant ABS or PP with ranking UL 94V-0 by model.

ü   Standby use.

ü   High rate discharge construction.Battery Rechargeable Aaa

ü   Deep discharge recoverability.

ü   Batteries are strictly tested by our patented computer charge/discharge system.

ü   ISO9001, 14001, OHSMS 18001 certified.

ü   UL recognized components under UL 1989 (file number MH14533).

ü   Complies with IATA/ICAO Special Provision A67 for air transport.

ü   Classified per MG Amendment 27 as a non-hazardous material for water transport.

ü   Recognized by DOT as "Dry charge" 49 CFR 171-189 for surface transport.

Battery_Series_Long_Life_s





International certifications:

  • ISO9001 approval, FN: Q3105105131
  • ISO14001 CTC04912E10302ROM
  • OHS MS18001 04912S10150ROM
  • UL approval, FN:MH28204
  • CE approval, FN:G2M20201-0102-E-16
  • KS approval, FN:KS C 8519
  • VDS approval
  • BS approval

General Features

  • Nonspillable
  • Sealed and Maintenance-free Operation
  • Front terminal,convenience for facilitate testing and servicing.
  • High Quality and High Reliability
  • Exceptional Deep Discharge Recovery
  • Low Self-discharge
  • Long Service Life
  • Solid Copper Terminals
  • Tank-formed Plates
  • Computer-aided Design and Manufacturing
  • UL, CE, VdS Approved


Typical Applications

  • 1.UPS and EPS
    2.Emergency lightp
    3.Railway signal and aircraft signal system
    4.Marine and power stations
    5.Alarm and security system;
    6.Electronic apparatus and equipment
    7.Communication power supply, DC power supply


Specifications

Nominal Voltage

12 V

Capacity

(25)

20HR(10.5V)

28 Ah

10HR(10.5V)

26Ah

1HR(9.60V)

17.6Ah

Dimension

Length

165±2mm (6.50inch)

Width

125±1mm (4.92inch)

Height

175±2mm (6.89inch)

Total Height

T6: 182±2mm (7.17inch)

T8: 175±2mm (6.89inch)

Approx. Weight

9.1kg (20.1lbs)±4%

Terminal type

T6/T8

Internal resistance

(Fully charged, 25)

Approx. 10mΩ

Capacity affected by temperature (20HR)

40

102%

25

100%

0

85%

-15

65%

Self-discharge

(25)

3 month

Remaining Capacity: 91%

6 month

Remaining Capacity: 82%

12 month

Remaining Capacity: 65%

Nominal operating temperature

25±3(77℉±5℉)

Operating temperature range

Discharge

-15~50(5℉~122)

Charge

-10~50(14℉~122)

Storage

-20~50(-4℉~122)

Float charging voltage(25)

13.60 to 13.80V

Temperature compensation:

-18mV/

Cyclic charging voltage(25)

14.50 to 14.90V

Temperature compensation:

-30mV/

Maximum charging current

8.4A

Terminal material

T6: Lead,  T8: Copper

Maximum discharge current

420A(5 sec.)

Designed floating life(20)

12~15 years

◆ Absorbent glass mat technology;

◆ Recognized by UL & CE;

◆ ABS container.



Constant Current Discharge Characteristics (A, 25)

F.V/TIME

10min

15min

30min

60min

2h

3h

4h

5h

8h

10h

20h

9.60V

64.0

51.2

28.6

17.6

9.95

7.14

5.71

4.86

3.14

2.64

1.42

9.90V

62.1

50.0

28.0

17.3

9.89

7.10

5.68

4.83

3.12

2.63

1.42

10.2V

59.5

48.1

27.1

16.8

9.80

7.05

5.64

4.79

3.10

2.62

1.41

10.5V

57.0

46.5

26.5

16.5

9.65

7.00

5.60

4.76

3.08

2.60

1.40

10.8V

53.8

44.0

25.5

16.0

9.41

6.79

5.43

4.62

2.99

2.55

1.37

Constant Power Discharge Characteristics (Watt, 25)

F.V/TIME

10min

15min

30min

60min

2h

3h

4h

5h

8h

10h

20h

9.60V

722

584

327

203

116

84.8

68.0

58.0

37.7

31.7

17.1

9.90V

700

570

321

200

116

84.3

67.6

57.6

37.5

31.6

17.0

10.2V

672

549

311

195

115

83.7

67.2

57.2

37.2

31.4

16.9

10.5V

643

530

303

191

113

83.2

66.7

56.8

37.0

31.2

16.8

10.8V

607

502

292

185

110

80.7

64.7

55.1

35.9

30.6

16.5

Note: The above characteristics data can be obtained within three charge/discharge cycles.
