LFP6200HR is a typical high rate discharge battery special designed for all kinds of high-power-ouput using application,
It is a non-spillable and sealed and Maintenance-free operation battery, with high quality and high reliability, good deep discharge recovery, low self-discharge ,etc. The battery apply solid copper terminals,tank-formed plates computer-aided design and manufacturing
Main features as follow:
* Standby use.
* High rate discharge construction.
* ISO9001, 14001, OHSMS 18001 certified.* UL, CE, VdS Approved. UL recognized components under UL 1989 (file number MH28204 ).
*With isolated seal, it can be put in horizontal way, vertical way and side way, its safety and functions totally will not be affected.
* With special formula to manufacture lead calcium alloy as well as automatic progresses, gassing will be less.
* Long life, low self-discharge rate and high reliability.
* It has safety, low resistance so recharge is easy and energy output is more remarkable.
* Container material could be frame retardant ABS or PP with ranking UL 94V-0 by model.
* When it is used in safe surroundings, the battery is maintenance free, adding water is unnecessary and it can be recharged repeatedly.
* Batteries are strictly tested by computer charge/discharge system.
* Complies with IATA/ICAO Special Provision A67 for air transport.
* Classified per MG Amendment 27 as a non-hazardous material for water transport.
* Recognized by DOT as "Dry charge" 49 CFR 171-189 for surface transport.
Specifications
|
Nominal Voltage |
6 V |
||
|
Capacity (25℃) |
10HR(5.40V) |
200Ah |
|
|
5HR(5.25V) |
180Ah |
||
|
1HR(4.80V) |
131Ah |
||
|
Dimension |
Length |
307±2mm (12.09inch) |
|
|
Width |
169±2mm (6.65inch) |
||
|
Height |
220±2mm (8.66inch) |
||
|
Total Height |
225±2mm (8.86inch) |
||
|
Approx. Weight |
32.0kg (70.5lbs)±4% |
||
|
Terminal type |
T11 |
||
|
Internal resistance (Fully charged, 25℃) |
Approx. 2.0mΩ |
||
|
Capacity affected by temperature (10HR) |
40℃ |
102% |
|
|
25℃ |
100% |
||
|
0℃ |
85% |
||
|
-15℃ |
65% |
||
|
Self-discharge (25℃) |
3 month |
Remaining Capacity: 91% |
|
|
6 month |
Remaining Capacity: 82% |
||
|
12 month |
Remaining Capacity: 65% |
||
|
Nominal operating temperature |
25℃±3℃(77℉±5℉) |
||
|
Operating temperature range |
Discharge |
-15℃~50℃(5℉~122℉) |
|
|
Charge |
-10℃~50℃(14℉~122℉) |
||
|
Storage |
-20℃~50℃(-4℉~122℉) |
||
|
Float charging voltage(25℃) |
6.75 to 6.90V Temperature compensation: -9mV/℃ |
||
|
Cyclic charging voltage(25℃) |
7.25 to 7.45V Temperature compensation: -15mV/℃ |
||
|
Maximum charging current |
60A |
||
|
Terminal material |
Copper |
||
|
Maximum discharge current |
1600A(5 sec.) |
||
|
Designed floating life(20℃) |
7~10 years |
||
◆ Absorbent glass mat technology;
◆ Recognized by UL & CE;
◆ ABS container.
Constant Current Discharge Characteristics (A, 25℃)
|
F.V/TIME |
5min |
10min |
15min |
20min |
30min |
45min |
60min |
2h |
3h |
4h |
5h |
10h |
20h |
|
1.60V/cell |
696 |
464 |
379 |
304 |
215 |
160 |
131 |
73.1 |
52.4 |
42.2 |
36.7 |
20.5 |
10.9 |
|
1.65V/cell |
675 |
450 |
370 |
296 |
211 |
157 |
129 |
72.6 |
52.1 |
42.0 |
36.5 |
20.5 |
10.9 |
|
1.67V/cell |
664 |
443 |
368 |
291 |
208 |
155 |
127 |
72.4 |
52.0 |
41.9 |
36.4 |
20.3 |
10.9 |
|
1.70V/cell |
647 |
431 |
357 |
285 |
204 |
152 |
125 |
72.0 |
51.8 |
41.7 |
36.3 |
20.2 |
10.8 |
|
1.75V/cell |
619 |
413 |
345 |
276 |
199 |
149 |
123 |
70.9 |
51.4 |
41.4 |
36.0 |
20.1 |
10.8 |
|
1.80V/cell |
584 |
390 |
326 |
261 |
192 |
143 |
119 |
69.1 |
49.9 |
40.2 |
34.9 |
20.0 |
10.7 |
Constant Power Discharge Characteristics (Watt, 25℃)
|
F.V/TIME |
5min |
10min |
15min |
20min |
30min |
45min |
60min |
2h |
3h |
4h |
5h |
10h |
20h |
|
1.60V/cell |
1266 |
872 |
732 |
586 |
415 |
309 |
252 |
143 |
103 |
83.2 |
72.7 |
41.1 |
21.8 |
|
1.65V/cell |
1228 |
846 |
715 |
572 |
407 |
303 |
248 |
142 |
103 |
82.7 |
72.3 |
41.0 |
21.7 |
|
1.67V/cell |
1209 |
833 |
710 |
562 |
402 |
299 |
246 |
141 |
102 |
82.5 |
72.1 |
41.0 |
21.7 |
|
1.70V/cell |
1177 |
811 |
688 |
551 |
394 |
294 |
242 |
140 |
102 |
82.1 |
71.8 |
40.9 |
21.7 |
|
1.75V/cell |
1127 |
776 |
665 |
532 |
385 |
287 |
237 |
138 |
101 |
81.6 |
71.3 |
40.7 |
21.5 |
|
1.80V/cell |
1063 |
732 |
630 |
504 |
371 |
276 |
230 |
135 |
98.2 |
79.1 |
69.1 |
40.4 |
21.4 |
Note: The above characteristics data can be obtained within three charge/discharge cycles.
ISO9001 approval, FN: Q3105105131
ISO14001 CTC04912E10302ROM
OHS MS18001 04912S10150ROM
UL approval, FN:MH28204
CE approval, FN:G2M20201-0102-E-16
KS approval, FN:KS C 8519
VDS approval
BS approval
Typical Applications:
Alarm System
Cable Television
Communication Equipment
Control Equipment
Security System
Medical Equipment
UPS
Power Tools
Toys
Emergency Power System
