FP645HR is a typical high rate discharge battery special designed for all kinds of high-power-ouput using application,
It is a non-spillable and sealed and Maintenance-free operation battery, with high quality and high reliability, good deep discharge recovery, low self-discharge ,etc. The battery apply solid copper terminals,tank-formed plates computer-aided design and manufacturing
Main features as follow:
* Standby use.
* High rate discharge construction.
* ISO9001, 14001, OHSMS 18001 certified.* UL, CE, VdS Approved. UL recognized components under UL 1989 (file number MH28204 ).
*With isolated seal, it can be put in horizontal way, vertical way and side way, its safety and functions totally will not be affected.
* With special formula to manufacture lead calcium alloy as well as automatic progresses, gassing will be less.
* Long life, low self-discharge rate and high reliability.
* It has safety, low resistance so recharge is easy and energy output is more remarkable.
* Container material could be frame retardant ABS or PP with ranking UL 94V-0 by model.
* When it is used in safe surroundings, the battery is maintenance free, adding water is unnecessary and it can be recharged repeatedly.
* Batteries are strictly tested by computer charge/discharge system.
* Complies with IATA/ICAO Special Provision A67 for air transport.
* Classified per MG Amendment 27 as a non-hazardous material for water transport.
* Recognized by DOT as "Dry charge" 49 CFR 171-189 for surface transport.
Specifications
|
Nominal Voltage |
6 V |
||
|
Number of cell |
3 cells |
||
|
Capacity(15min.rate, 25℃) |
19 Watts/cell |
||
|
Dimension |
Length |
70±1mm (2.76inch) |
|
|
|
Width |
47±1mm (1.85inch) |
|
|
|
Height |
101±1mm (3.98inch) |
|
|
|
Total Height |
107±1mm (4.21inch) |
|
|
Approx. Weight |
0.8kg (1.76lbs)±5% |
||
|
Terminal type |
T1/T2 |
||
|
Internal resistance (Fully charged, 25℃) |
Approx. 15mΩ |
||
|
Capacity affected by temperature (20HR) |
40℃ |
102% |
|
|
|
25℃ |
100% |
|
|
|
0℃ |
85% |
|
|
|
-15℃ |
65% |
|
|
Self-discharge (25℃) |
3 month |
Remaining Capacity: 91% |
|
|
|
6 month |
Remaining Capacity: 82% |
|
|
|
12 month |
Remaining Capacity: 65% |
|
|
Nominal operating temperature |
25℃±3℃(77℉±5℉) |
||
|
Operating temperature range |
Discharge |
-15℃~50℃(5℉~122℉) |
|
|
|
Charge |
-10℃~50℃(14℉~122℉) |
|
|
|
Storage |
-20℃~50℃(-4℉~122℉) |
|
|
Float charging voltage(25℃) |
6.80 to 6.90V Temperature compensation: -9mV/℃ |
||
|
Cyclic charging voltage(25℃) |
7.25 to 7.45V Temperature compensation: -15mV/℃ |
||
|
Maximum charging current |
1.35A |
||
|
Terminal material |
Copper |
||
|
Maximum discharge current |
67.5A(5 sec.) |
||
|
Designed floating life(20℃) |
10 years |
||
◆ Specially designed for high power output.
◆ Absorbent glass mat technology;
◆ Recognized by UL & CE;
◆ ABS container.
Constant Current Discharge Characteristics (A, 25℃)
F.V/TIME
5min
10min
15min
20min
30min
45min
60min
3h
5h
10h
1.60V/cell
20.8
12.7
10.0
7.95
5.51
3.95
3.12
1.17
0.80
0.43
1.65V/cell
20.2
12.4
9.79
7.76
5.40
3.87
3.07
1.16
0.80
0.43
1.67V/cell
19.9
12.2
9.63
7.63
5.33
3.82
3.04
1.16
0.80
0.43
1.70V/cell
19.3
11.8
9.43
7.48
5.23
3.75
2.99
1.16
0.79
0.43
1.75V/cell
18.5
11.3
9.11
7.22
5.11
3.66
2.93
1.15
0.79
0.43
1.80V/cell
17.5
10.7
8.63
6.84
4.92
3.53
2.84
1.11
0.76
0.42
Constant Power Discharge Characteristics (Watt, 25℃)
F.V/TIME
5min
10min
15min
20min
30min
45min
60min
3h
5h
10h
1.60V/cell
40.7
25.3
19.8
15.7
10.9
7.78
6.14
2.34
1.61
0.87
1.65V/cell
39.9
24.9
19.3
15.3
10.6
7.63
6.05
2.33
1.60
0.86
1.67V/cell
38.5
24.5
19.0
15.0
10.5
7.53
5.99
2.32
1.59
0.86
1.70V/cell
36.7
24.0
18.6
14.7
10.3
7.39
5.90
2.31
1.59
0.86
1.75V/cell
35.2
23.5
17.9
14.2
10.1
7.21
5.78
2.30
1.58
0.86
1.80V/cell
33.2
22.7
17.0
13.5
9.7
6.95
5.60
2.23
1.53
0.84
Note: The above characteristics data can be obtained within three charge/discharge cycles.
ISO9001 approval, FN: Q3105105131
ISO14001 CTC04912E10302ROM
OHS MS18001 04912S10150ROM
UL approval, FN:MH28204
CE approval, FN:G2M20201-0102-E-16
KS approval, FN:KS C 8519
VDS approval
BS approval
Typical Applications:
Alarm System
Cable Television
Communication Equipment
Control Equipment
Security System
Medical Equipment
UPS
Power Tools
Toys
Emergency Power System
