100W DC 12V Slim LED Driver IP20 , Indoor LED Power Supply
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Guangdong,China |
|---|
Non-waterproof DC 12V Slim LED Driver 100W IP20 Indoor for LED Lighting
1. Features
Small and compact size, light weight, hot selling in the market,
Constant voltage design, IP20, use indoor
Universal AC input / Full range
100% full load burn-in test,Low cost, high reliability
All of our products guarantee 2 years warranty
2. Specification
| Model | CJ100 - W1V12 |
| AC input voltage range | 100 - 264VAC 47 - 63HZ |
| Input Current | 1.5A / 115V 0.8A / 230V |
| AC inrush current | Cold - start current 20A / 115V 40A / 230V |
| Leakage current | < 1 mA / 240 VAC |
| DC adjustable range | + - 10% rated output voltage |
| Over load protection | 105-135% hiccup mode, auto-recovery |
| IP grade | IP20 |
| Setup rise hold up time | 200ms 100ms 30ms |
| Withstand voltage | I / P - O / P : 1.5 KvAC 1 minute |
| I / P - FG : 1.5 KvAC 1 minute | |
| O / P - FG: 0.5 KvAC 1 minute | |
| Working temperature | ~10 ° c~+60 ° c , 20%~90% RH |
| Weight / packing / Size | 0.25kg , 50pcs / 14.10 kg , 196*53*44 mm |
| Efficiency | 85% |
3. Competitive Advantage
1. All of our power supply guarantee all use new material.
2. Each of our product have been 4 hours of aging time.
3. All products have to pass 4 times inspection before they go out.
4. Test equipments, we have SM - 268 ACTIVE load, Withstand voltage test, Oscilloscope ……
Welcome to contact us for details, looking forward to a nice cooperation with you!
