10/100/1000M Gigabit Sfp Media Converter With 256K External
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Guangdong,China |
|---|
10/100/1000M Gigabit Sfp Media Converter With 256K External Power One SFP GE Slot
Quick Details
- Place of Origin: Guangdong, China (Mainland)
- Brand Name: OPTFOCUS
- Model Number: OFS-GAS-1
- temperature: -20 - +70
- Data Buffer: 256K
- MAC Adress cable: 4 k
Packaging & Delivery
| Packaging Details: | According to customer's requirements |
|---|---|
| Delivery Detail: | 3-5 Days after payment received |
Specifications
1. gigabit SFP media converter 10/100/1000m 1310nm SC 20KM~80KM 2.10/100/1000base-tx- 2 SFP fiber meidia converter
1.gigabit SFP media converter 10/100/1000m 1310nm SC 20KM~80KM
OFS-GAS-1 Series
Type
1. 10/100/1000M SFP Media converter / SFP Converter / SFP Fiber converter
2. 10/100/1000M SFP Slots Media Converter(Without SFP Module)
3. Dimensions:
Internal Power: 40 (high) x 110 (width) x 140 (length) mm
External Power: 26 (high) x 70 (width) x 93 (length) mm
Fiber Information
|
Model |
Connector |
Fiber type |
Max distance |
Wavelength |
TX power |
Sensitivity |
Link Budget |
|
1000Base-SX |
LC |
Multimode |
224/ 550m |
850nm |
-11-6dBm |
-18dBm |
7dBm |
|
1000Base-LX-10 |
LC |
Singlemode |
10km |
1310nm |
-12- 5dBm |
-21dBm |
9dBm |
|
1000Base-LX-30 |
LC |
Singlemode |
30km |
1310nm |
-80dBm |
-25dBm |
17dBm |
|
1000Baee-HX |
LC |
Singlemode |
70km |
1550nm |
-50dBm |
-25dBm |
20dBm |
Order Information
|
Model |
Product description |
|
OFS-GAS-1 |
10/100/1000M SFP Slots Media Converter, without SFP module |
|
SFP Module |
1.25G SFP module, multimode or singlemode or singlemode single fiber, 850nm, 1310nm, 1550nm |
Payment & Shipping Terms
Minimum Order Quantity: 1~2piece/pieces
Port: Shenzhen
Packaging Details: 20pcs/carton 48.5*32.5*34 cm/carton, 8.6KGS/carton
Delivery Time: 3~5 days
Payment Terms:T/T ,L/C
Supply ability: 1000 Piece/Pieces per Week
Warranty: 1 years
