2400-2500MHz 2.4GHz Yagi Antenna WIFI Wlan Antenna 18dBi High Gain Outdoor Directional Antenna
- Payment Type:
- T/T, Western Union, paypal
- Transportation:
- Ocean, Land, Air
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Payment Type: | T/T,Western Union,paypal |
| Transportation: | Ocean,Land,Air |
| ELECTRICAL | |
| Model | DT-YA2400-18 |
| Frequency Range | 2400-2500MHz |
| Gain | 18dBi |
| Beamwidth | H: 35° , E: 30° |
| VSWR | ≤1.5 |
| Polarization | Vertical |
| Max power | 100W |
| Nominal Impedance | 50Ω |
| Lightning Protection | DC Ground |
| MECHANICAL | |
| Connector | N Female or customized |
| Antenna Dimension | 820mm |
| Weight | 0.6kg |
| Radome Material | Aluminium |
| Rated Wind Velocity | 60m/s |
| Elements | 18 |
