glass bottles coating machine

Automatic spray coating machine for glass bottle.

Production Features:

Operate easy and simple,single person can operate it
Mini type,Occupy small area
Automatic spraying,high efficiency, Save labor cost
Factory Price,Competitive price
High quality,One year Warranty

Detailes:

1,The machine size:The dimension: L1500mm x D1000mm x H140mm (1 set)

2,The rack is made of welding 50# square box section. The bottom of rack has the truckle and foot cup. The height is adjustable. The rack is sealed by the plate,The structure is compact and generous.

3,The conveyor chain use special chain of automatic line. the pitch is 50.8mm,the total length is 5.1m. Each two pitch distance use one special fixture for the product.

4,The motor use Taiwan imported 0.5HP gear reducer motor to transmission. The speed of

chain is adjusted by adopting 1HP ZONCN frequency transformer. The chain speed is adjustable within 0.1m/min- 5m/min. The frequency control of the motor speed  is energy saving.

5,It has two sets of special friction system, The motor adopts 200W electronic speed regulating motor. It can positive and negative rotation.

6,The electronic control is mainly use China famous brand CHINT brand.The indicator light, the switch,relay and contacts are equipped with the overload protection.The parts of Electronic Control is placed in the below of racks.

7,The automatic spray-gun use Japan ANEST WF-60B automatic spray gun. The caliber is 1.0mm. The qty of the guns is six. A set of adjustable support brackets is equipped.

8. Two sets of trisection diaphragm pumps are equipped.

9, It is equipped with relative oil pipe, Air pipe, pressure regulating valve,oil-water separator and a set of electric magnetic Valve.
