Battery driven toy car applied 4010 40mm 12V/ 24V DC Cooling Fan

  Product Description   Size: 40X40X10mm Frame and Impeller: Plastic P. B. T. Voltage: 5V, 12V, 24V Current: 0.04~0.25A Power: 0.45~1.44W Speed: 5000~8000RPM Air flow: 5.54~8.25CFM Pressure: 2.84~3.82(mmH2O) Noise: 23.87~33.25dBA Bear type: Sleeve, Two Ball  are Available Weight: 17G Motor: Brushless DC, auto restart Impedance & polarity protected Operation temperature: -20° C~80° C Insulation Resistance: 10 At 500VDC between lead and frame Dielectric Strength: 1 min at 500VAC/50-60Hz, current min 5mA Operation Humidity: 20%~85% Working voltage: Rated voltage± 15% Life at 25oC: Ball bearing 50, 000hrs and sleeve bearing 30, 000hrs       Motor Protection (Selective purchasing): 1.Automatic Restart. 2.Reverse Polarity Protected 3.Water proof for IP25, IP55 4.IC function RD ,FG and PWM control are available   * Two ball bearing applying * Applying NMB ball bearing inported from Japan * Short lead time 1 Week after confirm order   Application Packaging & Shipping     FAQ     Company Information
