china supplier 8L oxygen concentrator spare parts for water oxygen supply

  china supplier 8L oxygen concentrator spare parts for water oxygen supply     Descriptions: 1. Simple structure, easy to operate, and stable oxygen output. 2. Material: zeolite/alumina; each unit can work independently, and oxygen output can reach to 3-10 LPM or higher. 3. With chiller for cooling air, no need additional refrigerant dryer for reducing cost. 4. Oxygen purity can up to 90+5%. Two oxygen cylinders exchange working, auto drain water, nitrogen and other impurities output. 5. Parts with shipping: air compressor, chiller. 6. Oxygen outlet pressure: 0.06-0.08Mpa. With the technology of pressure swing adsorption (PSA), OGP-OL series oxygen generator uses special molecular sieves to absorb the oxygen from the air and remove impurities output and drain water automatically.  Oxygen purity is up to 90+-3%, and oxygen outlet pressure is 0.06-0.08 Mpa. With the technology of pressure swing adsorption (PSA), OGP-OL series oxygen generator uses special molecular sieves to absorb the oxygen from the air and remove impurities output and drain water automatically.  Oxygen purity is up to 90+-3%, and oxygen outlet pressure is 0.06-0.08 Mpa.

Item	Unit	Zeolite Material		High Efficiency Material
		OGP-O3L-1	OGP-O5L-1	OGP-O5L-2	OGP -O8L-2	OGP -O10L-2
Oxygen output	LPM	3	5	5	8	10
Oxygen concentration	%	90%±3%	90%±3%	90%±3%		90%±3%
Power	W	280	450		650	650
Pressure(inlet)	Mpa	0.18-0.2	0.2
Pressure(outlet)	Mpa	0.06-0.08
Temperature	℃	indoor temperature
Relative humidity	%	≤85%
Noise	Db	≤ 55	≤60		≤60	≤70
Dimension	mm	550×160×80	550×180×80	550×180×80	610×310×120	610×310×120
Weight	kg	9.25	16.70	16.74	19.10	19.10

Remarks: Above price including oxygen bed,air compressor,chiller,flowmeter.
