15W AC DC 12V 1A for set top box Adaptor comply with CE FCC GS

Specifications 1)12v /1a ac dc power supply

2)CE/FCC/RoHS

3)One year warranty

4)Factory direct price

5)Offer sample

    15W AC DC Adapter 12V 1.5A 2a for set top box comply with CE FCC GS   Feature: Universal AC Input/full Range Full Aging Testing Cost effective and reliable Level V compliant Fully enclosed plastic case MTBF>50,000 hours Erp Step2, CEC, MEPS Compliant 1  year warranty Product Parameter :

Model number		YK17
Input	Input connecting plug	USA
	Input voltage	AC100-240V,50/60Hz
Output	Output connector	5.5 * 2.1mm/others, 120cm/others
	Output voltage	DC 3-24V + / - 5%
	Max power	15W
	Ripple wave	(mVp-p): <1%
	Linear modulate	±0.5%max
	Temperature coefficient	±0.02%/°C
	Start time	≤3s(240VAC input,io=100%)
	Guard time	≥20ms(240VAC input,io=100%)
	Output standard	12V1A
Protection	Override protection	115%-200%vA,automatic recovery
	short-circuit protection	1 channel: automatic recovery
Insulation	Insulation strength	1500VAC/10mA,1MIN
	Insulation resistance	≥30MΩ,DC 500V
Environment	Working temperature	0°C-40°C,10%-90%RH
	Store temperature	-20°C-60°C,10%-90%RH
Size	Size	75*29*63mm
	Net weight	83G
