12V2A UL Certified Approved ac dc adapter with PSE certified
- Delivery Time:
- 7 Days
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Place of Origin: | Guangdong, China (Mainland) |
---|
Product Description
Product Description

Input connecting plug: US/EUR/UK/AUS and more 70cm (optional) Input voltage range: 100 to 240V AC, 50 to 60Hz Output connectors: 5.5 x 2.1mm and more, 90cm and more Output voltage: 3 to 24V DC ±5% Maximum power: 24W Ripple wave (mVp-p): <1% Linear modulate: ±0.5% (maximum) Temperature coefficient: ±0.02%/°C Start time: ≤3 seconds (240V AC input, Io: 100%) Guard time: ≥20 milliseconds (240V AC input, Io: 100%) Output standard: 12V2A UL Certified Approved ac dc adapter with PSE certified Over-ride protection: 115 to 200% VA, automatic recovery Short-circuit protection 1 channel: automatic recovery Insulation strength: 1,500V AC/10mA, 1 minute Insulation resistance: ≥30mΩ, 500V DC Environment working temperature: 0 to 40°C, 10 to 90% RH Storage temperature: -20 to 60°C, 10 to 90% RH Dimensions: 74 x 50 x 29mm Net weight: 168g
