Welcome to RayMing Technology!!!
Any question,pls contact Nail Ding freely.
Rayming Technology production facilities in China, has emerged as a well known Printed circuit boards manufacturer, and now also for turn-key Printed Circuit Board assembly service provider for low- to mid-volume electronic contract manufacturing. Rayming is well known for providing economical one-stop PCB assembly services, including PCB fabrication, sourcing of components, and complete electronic PCB assembly. With a state of the art facility and modern technology, we cater to customers primarily located in the United States and Canada in a broad spectrum of industries.
Factory Manufacture Capability.
| | Item | Capacity |
| 1 | Single and double sided SMT/PTH | Yes |
| 2 | Large parts on both sides, BGA on both sides | Yes |
| 3 | Smallest Chips size | 0201 |
| 4 | Min BGA and Micro BGA pitch and ball counts | 0.008 in. (0.2mm) pitch, ball count greater than 1000 |
| 5 | Min Leaded parts pitch | 0.008 in. (0.2 mm) |
| 6 | Max Parts size assembly by machine | 2.2 in. x 2.2 in. x 0.6 in. |
| 7 | Assembly surface mount connectors | Yes |
| 8 | Odd form parts:
LED
Resistor and capacitor networks
Electrolytic capacitors
Variable resistors and capacitors (pots)
Sockets | Yes,Assembly by hands |
| 9 | Wave soldering | Yes |
| 10 | Max PCB size | 14.5 in. x 19.5 in. |
| 11 | Min PCB Thickness | 0.02 |
| 12 | Fiducial Marks | Preferred but not required |
| 13 | PCB Finish: | 1.SMOBC/HASL
2.Electrolytic gold
3.Electroless gold
4.Electroless silver
5.Immersion gold
6.Immersion tin
7.OSP |
| 14 | PCB Shape | Any |
| 15 | Panelized PCB | 1.Tab routed
2.Breakaway tabs
3.V-Scored
4.Routed+ V scored |
| 16 | Inspection | 1.X-ray analysis
2.Microscope to 20X |
| 17 | Rework | 1.BGA removal and replacement station
2.SMT IR rework station
3.Thru-hole rework station |
