Wireless PIR Wall Mounting Detector / Pet Immunity/DUAL MW

Specifications Wireless PIR Wall Mounting Detector

1.CE Certificate

2.Pet Immunity

3.Anti-white light, Anti-EMI

4.Dual passive PIR

PE-7208P – Wireless PIR Wall Mounting Detector / Pet Immunity   PE-7208P is wireless PIR intrusion detector with pet immunity, it adopts PIR technology intruder detector designed to detect human body movement in a protected area, digital processing ensure a high immunity to false alarms and outstanding stability, it uses a sophisticated radio communication protocol with a high level of data safety, the detector make auto testing and report its status to the system for full supervision regularly, built-in tamper switch trigger alarm if there is any attempt to tamper with the detector, auto testing mode make testing in ease.   Features: anti-white light with spherical lens and sealed optical design adpots self-designed MASK chip with DMT technology reliable detection performance with dual passive PIR technology wireless detection distance: 9m@25°C / detection angle: 90° wireless emitting distance is 120 ~ 150 meter (in open area) pet immunity under 25kgs wireless emitting frequency is 433MHz / 868MHz working voltage is 3.0V DC (CR123A 3.0V Lithium Battery) Anti-EMI >30V/m(30MHz~1GHz) / Anti-White Light >8000LUX installation height 1.8 ~ 2.5 meter (6 ~ 8 feet) / single-sided corner mount at 45°to wall consumption current is 9uA(static)/20mA(alarm) alarm indication is LED light flash for 2 seconds operation temperature is -10°C to +50°C (14°F to 122°F) storage temperature is -20°C to +60°C (-4°F to 140°F) dimension is 95*64*49mm / ivory white color
