Computer UPS K 600VA-2000V

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Guangdong, China (Mainland)

Product Description

Specifications Offline UPS with RS-232 communication interface and USB(optional)

OFFLINE UPS: R-BK

Model No.	600N	800N	1000N	1500N
Power Capacity (VA/W)	600VA/360W	800VA/480W	1000VA/600W	1500VA/900W
Input
Nominal Voltage	120VAC/230VAC
Voltage Range	85-140VAC/140-300VAC
Frequnency Range	50Hz or 60Hz ±5Hz(auto sensing)
Output
Voltage	120VAC/230VAC±10%
Frequnency	Sync to input(line mode),50Hz or 60Hz±0.1%(battery mode)
Waveform Type	modified sinewave
Auto Retransfer	After overload recovering 100% load
Crest Power	3 times of ratings
Power Factor	>0.6
Batteries
type	Maintenance-free sealed Lead-Acid battery
Nominal DC Voltage	12VDC		24VDC
Estimated Runtime(minutes) (100W load)	20	29	45	70
Recharging Time	8 hrs to 90% of full capacity
Transfer time	< 6ms( standard mode)
Protections	overload,low battery,surge(custom-made)
LED DISPLAY	Operation mode(online-green,battery-yellow,fault-red)
Audible Alarm	Battery mode,Low battery,Overload,Battery repalcement,Fault.
Output Sockets	NEMA5-15 (or IEC320) X 2PCS		NEMA5-15( or IEC320)X 2(OR 4)PCS
Comunications & Management
Interface Port	RS-232/USB(custom-made)
Enviromental
Operation Enviroment	0-40°C
Relative Humidity	0-95%RH(non-condensing)
Audible Noise	<40dB
Physical
Net Weight(KG)	6	6.5	13.8	14.2
Dimension,D X W X H(mm)	315X85X139		338X123X185
*Specifications are subject to change without prior notice.
