Offline Computer UPS/Standby UPS 500VA~1500VA
- Delivery Time:
- 15 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Guangdong, China (Mainland) |
|---|
Offline computer UPS as a backup UPS is specially designed for home and computer. It adopts CPU controlling and AVR protecting function to protect your computer and provide uninterrupted power, . Features: 1.Microprocessor control guarantees high reliability
2. Equipped with Boost and Buck AVR to stabilize input voltage
3. Built-in DC start function enables UPS to be started up without AC power supplied.
4. Smart RS-232 Communication Port with Free Download Software from the Internet.
5. Auto restart while AC recovery.
6. Compact size, light weight
7. Provides Modem/Phoneline Surge Protection.
8. Provides Overload Protection.
9. USB, RJ 45/11 Optional
Product Series | Offline UPS | ||
Model | KS 500/600 | KS 1000/1200 | |
Rated Power | Battery Power Backup (BPB) | 500VA/300W 600VA/350W | 1000VA/600W 1200VA/700W |
Auto Voltage Regulator (AVR) | 300VA | 600VA | |
Input | Nominal Voltage | 220VAC | |
Voltage Range | 162~286VAC | ||
Nominal Frequency | 50Hz ±5% | ||
Protection | Non-Fuse Breaker (NFB) | ||
Output on Battery | Voltage | 220Vrms ±10% | |
Frequency | 50Hz ±1Hz | ||
Output on Mains | A.V.R | 176~266VAC | |
Battery | Type | Sealed Lead-Acid, Maintenance free (Panasonic) | |
Backup Time | 10 min / 18 min | ||
Recharge Time | 4-6Hours max. | ||
| Overload Capability
| Line Mode | BPB: 110% for 1 min, 130% immediate shutdown | |
AVR: NFB | |||
Battery Mode | BPB: 110% for 10 sec., 130% immediate shutdown | ||
LED indicators | Type | Red and Green LED | |
Status | Normal , Back up, Overload, Fault | ||
Audible Alarm | Battery discharge | Beeping sound every four seconds after utility power fails. Every second if battery approaches final discharge | |
Fault | Continuous beeping sound | ||
Acoustic Noise | At 1 meter distance | < 45 dBA | |
Output Receptacles | Type | IEC320 or NEMA5-15R | |
BPB | 3 pieces | 4 pieces | |
AVR | 2 pieces | ||
Network Surge Protection Port | RJ45 Connector | Network (RJ45) or Fax/Modem (RJ11) compatible jacks | |
Communications | DB-9 Port | ||
Environmental | Operating Temperature | 0 ~ 40°C | |
Relative Humidity | 20% ~ 90% Non-condensing | ||
Weight | Net/Gross (kg) | 4.8/5.3 | 8.3/10 |
Dimensions | W x D x H (mm) | 425 x 400x 455 | 422 x 364x 475 |
