High Frequency LCD/LED ONLINE UPS
- Delivery Time:
- 20 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Guangdong, China (Mainland) |
|---|
1,INPUT:110V/220V
2,OUTPUT:110V/220V
3,LCD/LED DISPLAY
UPS,high frequency led/lcd ups Key Features True on-line double conversion technology with advanced microprocessor control Wide input voltage range Zero transfer time Protection against all type of power problems Self test while start of the UPS Site wiring fault warning On-battery power-on function Smart RS232 communication interface Intelligent slot available Sealed lead-acid, maintenance free battery Technical Specifications
Product Series | BS | |||
Model | BS1K/1KS | BS2K/1KS | BS3K/1KS | |
Rated Power | VA/W | 1kVA / 0.7kW | 2kVA / 1.4kW | 3kVA / 2.1kW |
Input | Nominal Voltage | 110VAC/220VAC | ||
Voltage Range | 60~138VAC/115 ~ 300VAC | |||
Frequency Range | 46~54Hz(default), user adjustable within 40~60Hz | |||
Power Factor | 0.97 | |||
Output | Voltage | 110VAC/220VAC ± 2% | ||
Frequency | 46~54Hz or 50Hz ± 0.2Hz (Line mode) | |||
Waveform | Sine Wave | |||
Distortion | 3% | 4% | ||
Overload Capability | 108%~150% for 30 sec., ±150% for 300 ms | |||
Current Crest Ratio | 3:1 | |||
Battery | Type | Sealed, Maintenance free, Lead-Acid (Panasonic) | ||
Recharge Time | 5 hrs to 90% of capacity after full load discharge | |||
| Bypass
| Automatic Transfer | on overload and UPS failure | ||
Before UPS Power-on | Default “NO”, user adjustable to “YES” | |||
Voltage Range | 80~264VAC (Default), user adjustable within 80~286VAC | |||
Transfer Time | 0 ms; less than 4 ms from inverter to bypass and vice versa | |||
| LED/LCD Indicators | Status | Load level / Battery level, Battery , Utility Power, Inverter, Bypass, Overload, Fault | ||
Audible Alarm | Bypass, On battery mode, Battery low, Overload, Fault | |||
Acoustic Noise | At 1 meter distance | 45 dBA | 50 dBA | |
Communications | DB-9 Port | RS-232 Serial Interface | ||
Intelligent Slot | Options: WebPower, AS400 Card or WinPower CMC | |||
Environmental | OperatingTemperature | 0 ~ 40°C | ||
Operating Humidity | 20 ~ 90% non-condensing | |||
Weight | Net (Kg) | 14/7 | 34/13.5 | 34.5/14 |
Dimensions | W x D x H (mm) | 145*400*220 | 192*460*340 | |
