high efficiency dc motor ac to dc power inverter sma solar inverter

Model

SR-IV1000

Input

Rated capacity(W)

1000W

Commercial Power range(VAC)

100/110/120/127/220/230(+25%,-35%)

Frequency(Hz)

60/50±10%

Output

AVR voltage range(VAC)

100/110/120/127/220/230±10%(Auto-sensing)

Transfer time

9ms

Waveform

(sine)

Frequency

60/50±0.5

Commercial power supply: shared frequency with the commercial inversion state:60/50±0.5

protection

overload

100-120%30> 120%,100;>150% ,50 150.

Input/output over high or low protecting; low battery protecting; surge and pike-currents protecting; overload protecting 100%-120% 30sec;120% 100ms; 150%, 50ms output short circuit <150ms

Battery

DC Voltage

24/48VDC

TYPE

Sealed, maintenance-free lead acid

Recharge current

15A Maximum)

Battery protection

Automatic self-test, discharge protection, over-charging protected, smart management system.

Appearance

External Size(mm)

D×W×H

388*145*210

Size(mm) D×W×H

480*220*280(1piece)

Net weight(kg)

14

Gross weight(kg)

15.5
