High quality 10W small PV solar panels solar module india

High quality 10W small solar panels solar module india our factory make mono/poly solar panels from 1w-320w,solar system, solar lights and so on.     Materials of solar panel  1).Solar Cell------polycrystalline solar cell 156*156mm 2).Front Glass-------3.2mm, high transmission, low iron, tempered glss 3).EVA-------excellent anti-aging EVA 4).TPT-------TPT hot seal made of flame resistance 5).Frame------anodised aluminum profile 6).Junction Box-------lp54 rated, high quality, with diode protection Superiority: high quality anodexed aluminum frame, high efficiency long life, easy installation, strong wind resistance, strong hail resisance.   Features  1. High cell efficiency with quality silicon materials for long term output stability    2. Strictly quality control ensure the stability and reliability, totally 23 QC procedures    3. High transmittance low iron tempered glass with enhanced stiffness and impact resistance    4. Both Polycrystalline and Monocrystalline    5. Excellent performance in harsh weather    6. Outstanding electrical performance under high temperature and low irradiance   Quality assurance testing Thermal cycling test   Thermal shock test   Thermal/Freezing and high humidity cycling test   Electrical isolation test   Hail impact test   Mechanical, wind and twist loading test   Salt mist test   Light and water-exposure test   Moist carbon dioxide/sulphur dioxide     Electrical Characteristics                                 SR-Solar 3W Mono solar panel

SN	Item	Specification
1	Maximum Rated Power	10
2	Power Tolerance	±1.5%
3	Maximum Power Voltage	18.5
4	Maximum Power Current	0.61
5	Open Circuit Voltage-Voc	21.5
6	Short Cricuit Current-Isc	0.54
7	Maximum System Voltage	600
8	Cell Transfer Effienciency	17.5
9	Transfer Efficiency	17
10	Cell Number&Size	36 cells(125×125)in a 4×9 matrix connection in series
11	Cell Type	Poly Crystalline 125*125
12	Cable Type&Diameter	4mm2(12AWG),TUV
13	Connector Type	N/A
14	Juntion Box	PV-RH701 (TUV)
15	Number of Bypass Diodes and Type	2Nos,Schottky By-pass diodes
16	Maximum Series Fuse Rating	3
17	Temperature Coefficient of Power	-(0.47±0.05)%/°C
18	Temperature Coefficient of Voc	-(0.34±0.01)%/°C
19	Temperature Coefficient of Isc	-(0.055±0.01)%/°C
20	Nominal Operating Cell Temperature-NOCT	45±2
21	Standard Test Condition	STC:AM=1.5,1000W/m2,Cells Temperature 25°C
22	Operating Temperature	-40~+85
23	DimensionA*B*C	345*285*20mm
24	Weight	105kg
25	Construction	Super Strate:High transission 3.20mm temperedlow iron glass;Substrate: WhiteBacksheet;Encapsulant:Fast Cure EVA
26	Frame	Anodized aluminium alloy

   our factory picture        If any question,pls let us know quickly,we will try our best to solve it.   My skype is srsolar04,and my trademanager is cn1500136335
