polycrystalline solar panel solar cell with price in china

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Guangdong, China (Mainland)

Product Description

polycrystalline solar panel solar cell with price in china

Country of Origin:

Brand Name:

Primary Competitive Advantages:

Main Export Markets:

Key Specifications/Special Features:

Item numbers: SR125M-160, SR125M-170SR125M-180, SR125M-190, SR125M-200 and SR125M-220
Mono: supported
Maximum: 160, 170, 180, 190, 200, 210 and 220Wp
Open-circuit voltage (Voc): 42.8, 43.6, 44.2, 45, 45.5 and 46.0V
Optimum operating voltage (Vmp): 35.5, 35.8, 36.8, 37.2, 37.6 and 38.0V
Short circuit current (Isc): 5.15, 5.25, 5.35, 5.5, 5.73 and 5.95A
Optimum operating current: 4.51, 4.76, 4.9, 5.10, 5.31 and 5.52A
Module efficiency: 14.25, 15.00, 16.00, 16.80, 17.25 and 18.50%
Solar cell efficiency: 15.00, 15.75, 16.75, 17.5, 18.50 and 19.20%
Number of cells: 72 pieces (6 x 12)
Size of cell: 125 x 125mm (mono)
Size of module: 1580 x 808 x 46mm
Maximum system voltage: 1000V
Temperature coefficients of Isc (%): +0.1/°C
Temperature coefficients of Voc (%): -0.38/°C
Temperature coefficients of Pm (%): -0.47/°C
Temperature coefficients of Im (%): +0.1/°C
Temperature coefficients of Vm (%): -0.38/°C
Temperature range: -40 to 85°C
Surface maximum load capacity: 60m/s (200kg/m²)
Allowable hail load: steel ball fall down from 1m height
Weight per piece: 16kg
Junction box type: PV-RH701 (TUV)
Connectors and cables type: with TUV certificate
Length of cables: 900mm
Output tolerance: ±5%
Frame material: aluminum
Warranty: 2 years product warranty and 25 years 80% of power
FF: ≥72%
