Straight and Right Angle 2.0MM Wafer Connector

Straight or Right Angle 2.0MM Wafer Connector   Product Description Specifications:

Wafer (Straight)
Part No.	WF2001-WSXXW01
Part Name	WF2001 Wafer 180°
Positions	4~30 Circuits
Insulator	Nylon-66 or PBT UL94V-0
Contact	Brass
Plated	Tin-plated 50u'' Min
Color	White
SPECIFICATIONS
Current Rating	1.5AMP
Temperature Range	-40°C to +105°C
Contact Resistance	20mΩ Max.
Insulation Resistance	1000MΩ Min.
Withstanding Voltage	AC 500V



Wafer (Right Angle)
Part No.	WF2001-WRXXW01
Part Name	WF2001 Wafer 90°
Positions	4~30 Circuits
Insulator	Nylon-66 or PBT UL94V-0
Contact	Brass
Plated	Tin-plated 50u'' Min
Color	White
SPECIFICATIONS
Current Rating	1.5AMP
Temperature Range	-40°C to +105°C
Contact Resistance	20mΩ Max.
Insulation Resistance	1000MΩ Min.
Withstanding Voltage	AC 500V

Product Picture: Engineering Drawing:   Packaging & Shipping Packing:  Shipping: 1. If goods is not large: Fedex, DHL, EMS, UPS, TNT, ect express shipping method;   2. If goods is large: Sea or Air shipping method.   Company Information Our Company and Honor Certificates Complete Testing Equipments Advanced Production Equipments Our Other Products   FAQ Q1: Why choose our company? A: 1. Professional manufacturer since 2001, provide various kinds of precision cards, connectors and          combination cables.      2. Main customer:                3. Our MOQ is: 100 PCS(1 PCS for sample).      4. Good quality, competitive price with best service.      5. Available for ODM/OEM order.   Q2: How about samples? A: 20 Piece free sample is available, but you have to pay the freight fees.   Q3: What is your price term & payment terms?
A: 1. Our usual price term is EXW, but other terms is available too.
     2. Payment terms: T/T, Paypal and other terms.   Q4: What about your delivery time?
A: Usually 5-10 working days. If you are very urgent, we can negotiate.   Q5: What certificates do your factory have?
A: UL, SGS, RoHS, ISO9001:2008, ISO14001:2004, CQC, etc.   Dear friend, if you are interested in our products, pls send me your product information, We will surely quote for you in 24 hours, thank you!
