2.54mm juntion Box Header SMT

Specifications 1.ISO9001:2008/ISO14001:2004

2Specification is customized

3Experienced manufacturer

4ROHS,SGS,100%test

5Competitive price

2.54mm Box Header,SMT   1.Specification: Current      rating     :3Amp
Operation    temperature:-40 to 105°c
Contact      resistance :20mΩ max
Insulation   resistance :1000mΩ min
Withstanding voltage    :AC1000V
Insulator    material   :Polyster(UL94V-0)/Standard:PA6T
Contact      material   :Brass
Contact       plating    :AU or Sn over 50 u'' Ni     2.Engineering Drawing:         3.Box Header Product index:   1. Pitch  Series: 1.27/2.00/2.54mm   2.Tail & Mounting Type:   Straight DIP Type   3.DIP Spacing:  Single/Doublel row   4. Number of contacts: range from 1 up to 100 pins   5.Contact Plated:Gold flash/Gold 3u/ Gold 5u/ Gold 10u/ Gold 15u/ Gold 30u/Tin   6.Material Type: PPS/PBT/LCP/Nylon-66/Nylon-6T/PA46   7.Tires of Body: Single/Double/Triple tier 4.Our products:   4.Advantage:   1.All kinds of products passed ROHS,SGS, 100% tested before delivery.   2.Factory passed ISO9001:2008 and ISO14001:2004.   3.Available for ODM/OEM order.   4.Some plasitic have passed UL certificated.    5.Well-equipped testing facilities and strong technical force   6. Prompt delivery and competitive price and quality   7. Used in the most of home appliances,computer,PCB,LCD,TV Warmly welcome here inquiry!
