2.0mm Box Header waterproof connector with high quality

Specifications High quality/Free samples

Reasonable price

Prompt delivery

Certifications:ISO-TS16949 RoHS ISO9001:2008

Good after-sale

2.0mm BOX Header,SMT/Straight specification:
Current      rating     :1.5Amp
Operation    temperature:-40 to 105°c Contact      resistance :20mΩ max
Insulation   resistance :1000mΩ min
Withstanding voltage    :AC500V
Insulator    material   :Polyster(UL94V-0)/Standard:Nylon-66
Contact      material   :Brass
Contact       plating    :AU or Sn over 50 u'' Ni Engineering Draw           Box Header Product index: 1. Pitch  Series: 1.27/2.00/2.54mm 2.Tail & Mounting Type:   Straight DIP Type 3.DIP Spacing:  Single/Doublel row 4. Number of contacts: range from 1 up to 100 pins 5.Contact Plated:Gold flash/Gold 3u/ Gold 5u/ Gold 10u/ Gold 15u/ Gold 30u/Tin 6.Material Type: PPS/PBT/LCP/Nylon-66/Nylon-6T/PA46 7.Tires of Body: Single/Double/Triple tier Our Products index  Advantage: 1.All kinds of products passed ROHS,SGS, 100% tested before delivery. 2.Factory passed ISO9001:2008 and ISO14001:2004. 3.Available for ODM/OEM order. 4.Some plasitic have passed UL certificated.  5.Well-equipped testing facilities and strong technical force 6. Prompt delivery and competitive price and quality 7. Used in the most of home appliances,computer,PCB,LCD,TV 8.Our factory has nearly ten years manufacturing experience.
