female smt hdmi header connector

Specifications 1.Rich experience in manufacturing

2.ROHS SGS

3.100% tested before delivery

4.Free sample

5.Various types for choice

HDMI Connector, Female Type       SPECIFICATIONS:

Current Rating	0.5AMP
Operation Temperature	-25°C to +80°C
Contact Resistance	30mΩ Max.
Insulation Resistance	100MΩ Min.
Withstanding Voltage	AC 500V
Insulator Material	Polyester(UL94V-0) Standard: PA6T
Contact Material	Brass
Contact Plating	Au or Sn over 50 u'' Ni

        Engineering drawing:    Ordering Information:

Contact Plating	Color Type	Function
SN: Tin	B=Black	A=Solder Type
S0: Gold Flash/Tin	W=White	M=SMT Type
S1: 3u'' Gold/Tin
S2: 5u'' Gold/Tin
S3: 10u'' Gold/Tin
S4: 15u'' Gold/Tin
S5: 30u'' Gold/Tin
Standard:S0

      Our Advantages: 1.All kinds of our products have passed ROHS. 2.Our factory has passed the ISO9001:2000 certification and ISO1400 Certification. 3.We mainly produce the connectors which are used on the Internet,storage,digital computer and other related products. 4.We are glad to make samples according to your drawings and specifications. 5.Available for ODM/OEM order. 6.Please contact us so we can offer you the best quality,competitive price and timely delivery.
