5 pin mini usb smt

Specifications 1.Rich experience in manufacturing

2.ROHS SGS

3.100% tested before delivery

4.Free sample

5.Various types for choice

MINI USB 5P/F SMT TYPE       SPECIFICATIONS:

Electrical
Current-max[amps]	1.0A
Voltage-max[volts]	30V
Withstanding Voltage	100V AC
Contact Resistance[ohms]	50 milliohms max
Insulation Resistance[ohms]	100 Mehoms min
Temperature Range	0°C to +105°C
Material
Contact	Phosphor Bronze
Insulator	LCP UL94V-0
Shell	Brass
Plating
Contacts	Gold And Tin Plating
Shell	Tin Plating

      Engineering drawing:    Ordering Information:

Connector Type	Contact Plating	Color Type	Function
S=Straight	SN: Tin	B=Black	S=Solder Type
R=Right Angle	S0: Gold Flash/Tin	W=White	D=Dip Type
M=S.M.T.	S1: 3u'' Gold/Tin
	S2: 5u'' Gold/Tin
	S3: 10u'' Gold/Tin
	S4: 15u'' Gold/Tin
	S5: 30u'' Gold/Tin
	Standard:S0

      Our Advantages: 1.All kinds of our products have passed ROHS. 2.Our factory has passed the ISO9001:2000 certification and ISO1400 Certification. 3.We mainly produce the connectors which are used on the Internet,storage,digital computer and other related products. 4.We are glad to make samples according to your drawings and specifications. 5.Available for ODM/OEM order. 6.Please contact us so we can offer you the best quality,competitive price and timely delivery.
