cf pcmcl female connector smt

Specifications 1.Rich experience in manufacturing

2.ROHS SGS

3.100% tested before delivery

4.Free sample

5.Various types for choice

CF/pcmcl: Female Connector S.M.T. Type        SPECIFICATIONS:

MATERIAL
Insulator	LCP
Contacts	Phosphor Bronze
ELECTRICAL
Current Rating	0.5 Amps Max.
Contact Resistance	40mΩ Max.
Insulator Withstanding	1000MΩ Min.
Dielectric Withstanding	500V AC/minute
MECHANICAL
Mating Cycle	10,000 cycles
Mating Force	34.3 N Max.
Unmating Force	4.9 N Min./34.3 N Max.
Contact Retention	9.8 N Min.
Operating Temperature	-20°C to +80°C

      Engineering drawing:    Ordering Information:

Way Option	Contact Plating	03=BLACK
U=Top	G0: Gold Flash
D=Bottom	S0: Gold Flash/Tin
	S3: 10u'' Gold/Tin
	S4: 15u'' Gold/Tin
	S5: 30u'' Gold/Tin
	Standard: S0
