2.54mm dip plug connector

Get Latest Price

Delivery Time:: 7 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Guangdong, China (Mainland)

Product Description

Specifications 1.Rich experience in manufacturing

2.ROHS SGS

3.100% tested before delivery

4.Free sample

5.Various types for choice

2.54mm DIP Plug Connector SPECIFICATIONS:

Current Rating	3AMP
Operation Temperature	-40°C to +105°C
Contact Resistance	20mΩ Max.
Insulation Resistance	1000MΩ Min.
Withstanding Voltage	AC 1000V
Insulator Material	Polyester(UL94V-0) Standard: PBT
Contact Material	Brass
Contact Plating	Au or Sn over 50 u'' Ni

Engineering drawing:

Ordering Information:

No. of Contacts	Connector Type	Contact Plating	Option Type
04~80	P=Phosphor Bronze	SN: Tin	W=With Lock
	B=Brass	G0: Gold Flash	N=Without Lock
		G2: 5u'' Gold
		G3: 10u'' Gold
		G4: 15u'' Gold
		G5: 30u'' Gold
		S0: Gold Flash/Tin
		Standard:G0

Our Advantages: 1.All kinds of our products have passed ROHS. 2.Our factory has passed the ISO9001:2000 certification and ISO1400 Certification. 3.We mainly produce the connectors which are used on the Internet,storage,digital computer and other related products. 4.We are glad to make samples according to your drawings and specifications. 5.Available for ODM/OEM order. 6.Please contact us so we can offer you the best quality,competitive price and timely delivery.
