5.08mm Female header with dual row SMT type

Specifications 1.ISO9001:2008/ISO14001:2004.

2.Specification is customized

3.Experienced manufacturer

4.ROHS.SGS

5.competitve price

5.08mm Female header with dual row SMT type   Specification:   Current      rating     :7.5Amp
Operation    temperature:-40 to 105°c   Contact      resistance :20mΩ max
Insulation   resistance :1000mΩ min
Withstanding voltage    :AC/DC1000V
Insulator    material   :Polyster(UL94V-0)/Standard:LCP   Contact      material   :BRASS   Contact       plating    :AU over 50 u'' Ni   2.Engineering Draw:           3.Female  Header Product index:   1. Pitch  Series: 1.00/1.27/2.00/2.54/3.96/5.08/7.62mm   2.Tail & Mounting Type:   Straight DIP Type   3. Insulator Height: 2.1mm/4.3mm/3.4mm/4.0/4.6/4.9/6.35/5.0/8.5/5.7/7.1/6.8/ and so  on.   4.DIP Spacing:  Single/Doublel row   5. Number of contacts: range from 1 up to 100 pins   6.Contact Plated:Gold flash/Gold 3u/ Gold 5u/ Gold 10u/ Gold 15u/ Gold 30u/Tin   7.Material Type: PPS/PBT/LCP/Nylon-66/Nylon-6T/PA46   8.Tires of Body: Single/Double/Triple tier   4.Advantage:   1.All kinds of products passed ROHS.   2.Some plasitic have passed UL certificated.   3.Available for ODM/OEM order.   4.Please contact us so we can offer you the best quality,competitive price and timely delivery.   5.Our Factory has passed the ISO9001:2000 certification and ISO1400 Certification.   6.Well-equipped testing facilities and strong technical force.     Warmly welcome here inquiry!
