OPTO / SILAN P20 Outdoor Advertising LED Display with Static Scan
Quick Detail:
1. OPTO / SILAN LED;
2. 2,500 dots/sqm;
3. R9 GB10×12 chip size;
4. MBI5024 driving IC;
5. 320×160 mm module size;
6. More than 6000 nits/sq.m.
Detail Description:
Power supply is 110V/60HZ and 220V/50HZ convertible, with CE standard;
Control PC operates with the display simultaneously;
Long distance like 10km could be achieved by using optical fiber.
Specifications:
Pixel Pitch | 20mm |
Pixel Composition | 2R1G1B |
LED Encapsulation | DIP546 |
Pixel | 2,500 dots/sq.m |
Module Pixel | W 16 × H 8 |
Module Size | W 320 × H 160 mm |
Standard Cabinet Size | W 1280 × H 960 mm |
Cabinet Color | Black |
Cabinet Material | Steel waterproof |
Drive Method | Static scan |
Brightness | ≥6000 nits/sq.m |
Refresh Rate | ≥800Hz |
Out of Control Dot Rate | ＜0.0001 |
Earth Leakage Current | ＜2mA |
MTBF | ＞5,000 hours |
LED Life Span | ＞100,000 hours |
Power Supply | 110V/60HZ and 220V/50HZ interchangeable |
Humidity | 10%~90% |
Control Method | Synchronous control with PC on |
Operation System | Win2000 / XP / Vista |
