energy saving P7.62 indoor LED screen iron cabinet for fixed installation
Specifications:
|
Unit module |
Pixel pitch |
7.62 mm |
|
Pixel density(dots/sqm) |
17222/sqm |
|
|
LED encapsulation |
SMD3528 |
|
|
Driving method |
1/8 |
|
|
Module size(mm) |
244*122mm |
|
|
Resolution of module( dots) |
32*16 |
|
|
Major technical parameters |
Cabinet size |
976*732mm |
|
Brightness |
2000cd/ ㎡ |
|
|
Refresh rate |
>2000HZ |
|
|
Color temperature |
6500K |
|
|
View angle(H/V) |
160°/140° |
|
|
Grey scale |
16bit |
|
|
Brightness adjustment |
256 grade/ Manually/ Automatically |
|
|
Working/ storage temperature |
-20℃~50℃/ -30℃~60℃ |
|
|
Working/ storage humidity |
10%~90% RH |
|
|
Working voltage |
AC220/110V 50Hz |
|
|
Protect degree |
IP43 |
|
|
MTBF |
>5000h |
|
|
Life span |
100000h |
|
|
Input Signal |
AV, S-VIDEO, VGA, DVI, HDMI, SDI, DP |
|
|
Operation system |
Windows 7/XP |
|
|
Control distance |
cat-5 data cable:<100m, optical fiber<15km |
Quick details:
Pitch: P7.62 indoor LED video wall
module resolution: 32*16
module size; 244*122mm
cabinet size:976*732mm
Description:
1. Good performance price ratio for big screen: P7.62 is a good chioce for indoor big screen.
2. High refresh rate: BAKO indoor LED display is with high refresh rate and it is suitable for various occasions for camera. Refresh rate can be above 2000 nits.
3. high grey scale: grey scale is 16 bits and the showing color is good.
4. both front and rear service available: if the LED display is mounted on the wall, front service is better. We have our own design for front service and it is much convenient.
5. Wide view angle: for horizontal, the view angle is 160°and for vertical it is 110°. This is totally enough for indoor view.
6. Good color uniformity: We are very strict in LED lamp and both wave and brightness difference is controlled. This can ensure that the whole screen’s color uniformity is good.
7. Real color image: There are 281 trillion kinds of color. So LED screen can show vivid and real image.
8. slim cabinet: we will apply slim cabinet so it is convenient for handle.
Application:
meeting room
military
hotels
stage
motor show
