HR11 Series Online Rack UPS Power Supply 50HZ TUV CE , comm

Get Latest Price

Min. Order:: 1

Min. Order:: 1

Delivery Time:: 30 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China

Product Description

HR11 Series Online Rack UPS Power Supply 50HZ TUV CE , commercial ups battery backup

Description:

The RM600/30X Modular UPS provides power capacity of 600KVA in one single system. With the most advanced full DSP control technology, health management system and smart monitoring system, it has been proven to be the best choice for large data centers, as well as for sensitive electronics.

Features:

Wide range of input voltage while input PF>99%
 Output PF of 0.9
 Full protection of overvoltage, circuit short and over temperature
 Network/fax/modem surge protection
 LCD/LED display, monitoring all the operation status
 19 inch standard cabinet and battery cabinet
 Automatic fan speed adjustment
 Abundant interface:RS232,USB, SNMP, Intelligent Card

Specificaiton:

MODEL	HR1101S HR1101L	HR1102S HR1102L	HR1103S HR1103L	HR1106S HR1106L	HR1110S HR1110L
Capacity	1KVA	2KVA	3KVA	6KVA	10KVA
Input voltage range	110VAC~288VAC
	100% load@>176VAC; 80% load@>154VAC 70% load@>132VAC; 50% load@>110VAC
Input frequency	40-70Hz
Input PF	≥0.97			≥0.99
Voltage Regulation	±1 %
Output Frequency	50Hz
Output PF	0.9
Overload capability (Inverter mode)	105%~130%:to bypass 1 min; 150%: to bypass after 30sec			110%: to bypass after 10 min; 130%: to bypass after 1min; 150%: to bypass after 30 sec, Shutdown after 1min
Overload capability (Battery mode)	105%~130%:Shutdown after 10sec; >150%: Shutdown after 5sec			110%: Shutdown after 10mins; 125%:Shutdown after 10s; >125%:Shutdown after 1s
Crest Ratio	3:1
Efficiency	87%	91%	90%	92%
Display	LED+LCD
Battery	36VDC	72VDC	96VDC	192VDC
Interface	RS232,SNMP
Optional	USB, SNMP, Dry Contactor, Parallel Kit			USB, SNMP, ECO Kit, Dry Contactor, Parallel Kit, Battery Cabinet
Operation Temperature	0-40℃
Relative Humidity	0-95%(non-condensing)
WDH(mm)	44043086	440480173	440480173	438680218	438680218
	44043086	44048086	44048086	438680130	438680130
Net Weight(Kg)	13.5/8	28/9.5	33/10.5	62/18.5	70.5/21.5
