SV-D2T Headlight Tester(Electric),sv-d1t,sv-d2t,vehicle head lamp testers

Specifications SV-D2T Headlight Tester(Electric),vehicle head lamp testers

(hereinafter referred to as "tester"), boasts the advantages of acc

SV-D2T Headlight Tester(Electric)  vehicle head lamp testers  (hereinafter referred to as "tester"), boasts the advantages of accuracy measurement, simple installation and control the upward-downward by electronic, is used to detect the luminous intensity and the illuminating position (or the axis deviation).It is suitable for the auto manufacturer,vehicle repair unit and environmental- protection department.

Technical Parameters: 1. nominal range of usage      temperature:0-40;      relative humidity :≤80%;      power:AC220V-DC5V 2. Measurement range:      Luminous intensity:0-40000cd  0-80000cd      Axis deviation:      Vertical direction:Up1º20´~Down2º20´;      Horizontal direction:Left2º20´~right2º20´; 3. The indicated error for luminous intensity:±12%; 4. The indicated error for axis deviation:±15' 5. Measuring range of lamp height:0.4~1.3m; 6. testing distance:1m; 7. Weight:25kg.
